Single Row Deep Groove Ball Bearings 6005/W64JW

Single Row Deep Groove Ball Bearings 6005/W64JW

The 6005/W64JW is a single-row deep groove ball bearing with a 25mm bore and 47mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 2271 lbf and operates smoothly at speeds up to 15,000 RPM.
Its solid oil lubrication ensures long service life with minimal maintenance, while the open design allows for easy inspection. The bearing is built to ABEC 1 and ISO P0 tolerance standards for reliable performance.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or small machinery where radial loads are common.
Weighing just 80g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it works in temperatures from -30°C to 120°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6005/W64JW
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2271 lbf
  • Static Radial Load 1315 lbf
  • Max Speed 15000 rpm
  • Weight 80 g
Single Row Deep Groove Ball Bearings 6005/W64JW dimension drawing
Download DWG Download PDF

Features

Performance Features of 6005/W64JW Bearing

6005/W64JW Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.

Its dynamic radial load capacity reaches 2271 lbf, making it suitable for various industrial applications.

The solid oil lubrication ensures smooth operation and reduces the need for frequent maintenance.

With a maximum speed of 15,000 rpm, it provides reliable performance in high-speed conditions.

Application

Common Applications of 6005/W64JW Bearing
In industrial settings, 6005/W64JW Bearing is commonly used in electric motors and pumps, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, extending service life in demanding environments.

Where Is 6005/W64JW Bearing Used?
You’ll often find 6005/W64JW Bearing in automotive applications like alternators and small gearboxes, thanks to its reliable performance. Its solid oil lubrication makes it a low-maintenance choice for these components.

Ideal for Precision: 6005/W64JW Bearing
For medical devices such as dental drills, 6005/W64JW Bearing offers consistent performance due to its chrome steel construction. The ABEC 1 tolerance ensures smooth rotation in precision instruments.

Automotive vs Industrial: Applications of 6005/W64JW Bearing
In cars, 6005/W64JW Bearing handles radial loads in wheel hubs, while in factories, it supports conveyor rollers. Its versatility makes it a go-to for both light and medium-duty tasks.

Practical Applications of 6005/W64JW Bearing
Around the home, 6005/W64JW Bearing works well in appliances like washing machines, where durability matters. The wide temperature range also suits it for outdoor equipment.
