Single Row Deep Groove Ball Bearings 6005-RSH/C3

The 6005-RSH/C3 is a sealed single-row deep groove ball bearing, measuring 25mm by 47mm by 12mm. Made from chrome steel, it handles radial loads up to 2271 lbf and spins at speeds up to 15000 RPM.

Its sealed design keeps out dust and moisture, making it low-maintenance. The C3 radial clearance ensures smooth operation under varying temperatures, from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative. It’s well-suited for electric motors, pumps, or small machinery where reliability is key.

Weighing just 80g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use in various industries.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6005-RSH/C3
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Sealed
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No C3
Bore Dia 25 mm
Bore Dia Tolerance -0.01mm to 0
Outer Dia 47 mm
Outer Dia Tolerance -0.011mm to 0
Width 12 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 2271 lbf
Static Radial Load 1315 lbf
Max Speed 15000 rpm
Weight 80 g
price（$） 4.788

Single Row Deep Groove Ball Bearings 6005-RSH/C3 dimension drawing

Download DWG Download PDF

Features

Performance Features of 6005-RSH/C3 Bearing

6005-RSH/C3 Bearing is designed for radial loads, with a dynamic radial load capacity of 2271 lbf.

Its sealed construction protects against contaminants, ensuring smooth operation in various environments.

The chrome steel rings and balls provide durability, while the C3 radial clearance allows for thermal expansion.

With a maximum speed of 15,000 rpm, it offers reliable performance in high-speed applications.

Application

Common Applications of 6005-RSH/C3 Bearing
6005-RSH/C3 Bearing is widely used in industrial equipment like electric motors and pumps, where its sealed design helps keep out dust and moisture. The C3 clearance ensures reliable performance even under varying thermal conditions.

How Does 6005-RSH/C3 Bearing Improve Performance?
In automotive applications, 6005-RSH/C3 Bearing enhances the efficiency of alternators and water pumps, thanks to its smooth operation and radial load capacity. The chrome steel construction also extends its lifespan in demanding environments.

Perfect Fit for Automation: 6005-RSH/C3 Bearing
6005-RSH/C3 Bearing is a great choice for robotic arms and conveyor systems, where precision and durability are key. Its sealed design reduces maintenance needs, making it ideal for continuous operation.

Medical vs Industrial: Where 6005-RSH/C3 Bearing Excels
In medical devices like centrifuges, 6005-RSH/C3 Bearing offers quiet and reliable performance. Meanwhile, in industrial settings, it handles radial loads effortlessly, proving its versatility across sectors.

Light-Duty vs Heavy-Duty: Best Uses for 6005-RSH/C3 Bearing
For light-duty applications like small fans, 6005-RSH/C3 Bearing provides smooth rotation with minimal noise. In heavier machinery, its robust design ensures it can handle consistent radial loads without issue.
