Single Row Deep Groove Ball Bearings 6004 SS

Single Row Deep Groove Ball Bearings 6004 SS

The 6004 SS is a single-row deep groove ball bearing with a 20mm bore and 42mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2113 lbf and spins smoothly at speeds up to 17,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing operates well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where radial loads are common.

Weighing just 69g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6004 SS
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2113 lbf
  • Static Radial Load 1135 lbf
  • Max Speed 17000 rpm
  • Weight 69 g
Single Row Deep Groove Ball Bearings 6004 SS dimension drawing
Download DWG Download PDF

Features

Performance Features of 6004 SS Bearing

6004 SS Bearing is crafted with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 2113 lbf, ensuring reliable performance in various applications.
The open design allows for easy lubrication, maintaining smooth operation over time.
With a maximum speed of 17,000 rpm, it balances durability and efficiency for high-speed tasks.

Application

Common Applications of 6004 SS Bearing
6004 SS Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, making it suitable for high-speed environments.

In automotive applications, 6004 SS Bearing can be found in components like alternators and water pumps, providing reliable performance under varying loads. Its metric sizing ensures compatibility with a range of vehicle models.

For household appliances, 6004 SS Bearing is often used in fans and small electric tools, where its compact size and durability are advantageous. The chrome steel construction offers long-lasting performance in everyday use.

Automation systems benefit from 6004 SS Bearing in robotic arms and conveyor belts, where precision and reliability are key. The ABEC 1 tolerance ensures consistent performance in repetitive tasks.

Medical devices like centrifuges and lab equipment use 6004 SS Bearing for its smooth operation and resistance to wear. The temperature range makes it suitable for various clinical environments.
