Single Row Deep Groove Ball Bearings 6001-2Z/C3

The 6001-2Z/C3 is a compact single-row deep groove ball bearing, measuring 12mm by 28mm by 8mm, crafted from durable chrome steel. It handles radial loads up to 1147 lbf and spins smoothly at speeds up to 27,000 RPM.

Its shielded design keeps dirt out while maintaining smooth operation, and the C3 radial clearance ensures reliable performance under varying temperatures. The bearing works well in environments ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where space is limited but performance is key.

Weighing just 22g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6001-2Z/C3
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No C3
Bore Dia 12 mm
Bore Dia Tolerance -0.008mm to 0
Outer Dia 28 mm
Outer Dia Tolerance -0.009mm to 0
Width 8 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 1147 lbf
Static Radial Load 54 lbf
Max Speed 27000 rpm
Weight 22 g
price（$） 2.952

Single Row Deep Groove Ball Bearings 6001-2Z/C3 dimension drawing

Download DWG Download PDF

Features

Performance Features of 6001-2Z/C3 Bearing

6001-2Z/C3 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 1147 lbf, ensuring reliable performance in various applications.
The shielded design protects against contaminants while maintaining smooth operation.
With a maximum speed of 27,000 rpm, it delivers both durability and efficiency.

Application

Common Applications of 6001-2Z/C3 Bearing
In industrial settings, 6001-2Z/C3 Bearing is commonly used in electric motors and pumps, where its shielded design helps keep contaminants out. The C3 clearance ensures reliable performance even under varying thermal conditions.

Where Is 6001-2Z/C3 Bearing Used?
You’ll often find 6001-2Z/C3 Bearing in automotive applications like alternators and small gearboxes, thanks to its compact size and radial load capacity. Its chrome steel construction also makes it durable for long-term use.

Optimized for Performance: 6001-2Z/C3 Bearing
For household appliances like washing machines, 6001-2Z/C3 Bearing provides smooth operation with minimal maintenance. The shielded seals protect against dust and moisture, extending its lifespan.

Light-Duty vs Heavy-Duty: Best Uses for 6001-2Z/C3 Bearing
In light-duty applications such as office printers, 6001-2Z/C3 Bearing ensures quiet and efficient performance. For heavier tasks, it’s also suitable for small conveyor systems where radial loads are moderate.
