Single Row Deep Groove Ball Bearings 6001-2RSH/VA947

The 6001-2RSH/VA947 is a compact single-row deep groove ball bearing, measuring 12mm by 28mm by 8mm. Made from chrome steel with stainless steel cage, it’s built to last and handles radial loads up to 1214 lbf.

Its sealed design keeps grease in and dirt out, making it low-maintenance. With a maximum speed of 17,000 RPM, it spins smoothly and efficiently.

The bearing operates in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF bearings, offering a reliable replacement option.

Ideal for small machinery or electric motors where space is limited but performance is key. Compliant with RoHS and REACH standards, it’s a safe and durable choice.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6001-2RSH/VA947
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Sealed
Tolerance Class P6
Radial Clearance Trade No CN
Bore Dia 12 mm
Bore Dia Tolerance -0.007mm to 0
Outer Dia 28 mm
Outer Dia Tolerance -0.008mm to 0
Width 8 mm
Width Tolerance -0.12mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Stainless Steel
Lubrication Grease
REACH Compliant
Temperature Range -30° to 120 °C
Dynamic Radial Load 1214 lbf
Static Radial Load 531 lbf
Max Speed 17000 rpm
Weight 0.021 kg

Single Row Deep Groove Ball Bearings 6001-2RSH/VA947 dimension drawing

Download DWG Download PDF

Features

Why Choose 6001-2RSH/VA947 Bearing for Precision Tasks?

6001-2RSH/VA947 Bearing features a single-row deep groove design, ideal for handling radial loads with precision.
Its sealed construction protects against contaminants, ensuring smooth operation in various environments.

The chrome steel rings and balls provide durability, while the stainless steel cage maintains alignment.
With a maximum speed of 17,000 rpm, it offers reliable performance for high-speed applications.

6001-2RSH/VA947 Bearing operates efficiently in temperatures ranging from -30° to 120°C.
Its grease lubrication reduces maintenance needs, making it a practical choice for long-term use.

Application

Common Applications of 6001-2RSH/VA947 Bearing
6001-2RSH/VA947 Bearing is widely used in industrial equipment like conveyor belts and small motors, where its sealed design keeps contaminants out. The chrome steel construction ensures durability in dusty or humid environments.

In automotive applications, 6001-2RSH/VA947 Bearing fits well in electric window mechanisms and cooling fans. Its P6 tolerance class provides the precision needed for smooth, quiet operation.

For home appliances, 6001-2RSH/VA947 Bearing works reliably in washing machine pumps and kitchen mixer motors. The grease lubrication reduces maintenance while extending service life.

Automation systems benefit from 6001-2RSH/VA947 Bearing in robotic joints and small actuators. Its compact size and high-speed capability make it a versatile choice for precision movements.
