Single Row Deep Groove Ball Bearings 6001-2RSH/LHT23

Single Row Deep Groove Ball Bearings 6001-2RSH/LHT23

The 6001-2RSH/LHT23 is a compact single-row deep groove ball bearing, measuring 12mm in bore and 28mm in outer diameter, with a width of just 8mm. Made from durable chrome steel, it handles radial loads up to 1147 lbf and spins smoothly at speeds up to 27,000 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance for long-term use. The bearing operates well in temperatures from -30°C to 120°C, suitable for various environments.

This model is interchangeable with SKF bearings, offering a cost-effective alternative. Ideal for small motors, power tools, or appliances where reliable radial load support is needed.

Weighing only 22g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6001-2RSH/LHT23
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 28 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 27000 rpm
  • Weight 22 g
  • price（$） 3.42
Single Row Deep Groove Ball Bearings 6001-2RSH/LHT23 dimension drawing
Download DWG Download PDF

Features

Why Choose 6001-2RSH/LHT23 Bearing for Precision Tasks?

6001-2RSH/LHT23 Bearing features a sealed design, protecting against dust and moisture for consistent performance.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

With a dynamic radial load capacity of 1147 lbf, it handles demanding conditions reliably.
The bearing operates smoothly at speeds up to 27,000 rpm, making it suitable for high-speed applications.

Its compact size (12 mm×28 mm×8 mm) allows for easy integration into various machinery.
The temperature range of -30°C to 120°C ensures performance in diverse environments.

Application

Common Applications of 6001-2RSH/LHT23 Bearing
6001-2RSH/LHT23 Bearing is widely used in household appliances like washing machines and fans, where its sealed design keeps dust and moisture out. The chrome steel construction ensures long-lasting performance even with daily use.

In automotive applications, 6001-2RSH/LHT23 Bearing fits well in electric motors and alternators, providing smooth rotation under radial loads. Its metric size makes it a versatile choice for various vehicle models.

For industrial machinery, 6001-2RSH/LHT23 Bearing handles moderate loads in conveyor systems and pumps. The sealed type reduces maintenance needs, making it ideal for environments with dirt or debris.

In small electric tools like drills and grinders, 6001-2RSH/LHT23 Bearing offers reliable support for high-speed operations. Its compact size and durability make it a go-to option for DIY and professional tools alike.

Medical devices such as dental handpieces benefit from 6001-2RSH/LHT23 Bearing’s precision and low noise. The temperature range allows it to perform consistently in sterilisation processes.
