Single Row Deep Groove Ball Bearings 6000-ZTN9

Single Row Deep Groove Ball Bearings 6000-ZTN9

The 6000-ZTN9 is a compact single-row deep groove ball bearing, measuring 10mm in bore and 26mm in outer diameter, with a width of just 8mm. Made from chrome steel, it’s built to handle radial loads up to 1023 lbf and can spin at speeds up to 31,000 RPM.

Its shielded design keeps dust out while the nylon cage reduces friction, ensuring smooth operation. The bearing performs well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s ideal for small motors, fans, or appliances where reliable radial load support is needed.

Weighing only 19g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6000-ZTN9
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 26 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1023 lbf
  • Static Radial Load 438 lbf
  • Max Speed 31000 rpm
  • Weight 19 g
  • price（$） 2.754
Single Row Deep Groove Ball Bearings 6000-ZTN9 dimension drawing
Download DWG Download PDF

Features

How Does 6000-ZTN9 Bearing Reduce Friction?

6000-ZTN9 Bearing features a single-row deep groove design, optimised for smooth radial load handling.
The chrome steel construction ensures durability while reducing friction during operation.

Its shielded design protects against contaminants, maintaining performance in various environments.
With a maximum speed of 31,000 rpm, it delivers efficient and reliable performance.

The nylon cage helps minimise vibration and noise, making it suitable for precision applications.
Its temperature range of -30°C to 120°C ensures adaptability in different working conditions.

Application

Common Applications of 6000-ZTN9 Bearing
In industrial settings, 6000-ZTN9 Bearing works well in small electric motors and pumps, thanks to its shielded design that keeps out dust and debris. The chrome steel construction ensures it handles radial loads smoothly.

Where Is 6000-ZTN9 Bearing Used?
You’ll often spot 6000-ZTN9 Bearing in household appliances like washing machines and fans, where its compact size and reliability are key. The nylon cage reduces noise, making it ideal for quiet environments.

Built for Versatility: 6000-ZTN9 Bearing
This bearing fits neatly into office equipment like printers and scanners, where precision and durability matter. Its ABEC 1 tolerance ensures consistent performance without overcomplicating the design.

Light-Duty vs Heavy-Duty: Best Uses for 6000-ZTN9 Bearing
For light-duty tasks, 6000-ZTN9 Bearing shines in small tools and DIY gadgets, while its robust build also handles occasional heavy use. The temperature range suits both indoor and outdoor applications.
