Single Row Deep Groove Ball Bearings 6000-ZTN9/LT

The 6000-ZTN9/LT is a compact single-row deep groove ball bearing with a 10mm bore and 26mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1023 lbf and spins smoothly at speeds up to 31,000 RPM.

Shielded on both sides, it keeps dirt out while the nylon cage reduces friction for quieter operation. The bearing performs reliably in temperatures from -30°C to 120°C.

With ABEC 1 precision and CN clearance, it offers consistent performance for everyday use. Ideal for small motors, power tools, or appliances where space is limited.

Weighing just 19 grams, it’s lightweight yet durable. Compliant with RoHS and REACH standards, making it a safe choice for various applications.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6000-ZTN9/LT
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Bore Dia 10 mm
Bore Dia Tolerance -0.008mm to 0
Outer Dia 26 mm
Outer Dia Tolerance -0.009mm to 0
Width 8 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Nylon
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 1023 lbf
Static Radial Load 438 lbf
Max Speed 31000 rpm
Weight 19 g
price（$） 2.754

Single Row Deep Groove Ball Bearings 6000-ZTN9/LT dimension drawing

Download DWG Download PDF

Features

Performance Features of 6000-ZTN9/LT Bearing

6000-ZTN9/LT Bearing is designed for radial loads, with a dynamic radial load capacity of 1023 lbf.
Its chrome steel rings and balls provide durability, while the nylon cage ensures smooth operation.

The shielded design of 6000-ZTN9/LT Bearing protects against contaminants, extending its service life.
It operates efficiently at speeds up to 31,000 rpm, making it suitable for high-speed applications.

With a temperature range of -30°C to 120°C, 6000-ZTN9/LT Bearing performs well in various environments.
Its compact size (10 mm×26 mm×8 mm) makes it ideal for space-constrained applications.

Application

Common Applications of 6000-ZTN9/LT Bearing
6000-ZTN9/LT Bearing works well in small electric motors, thanks to its shielded design that keeps dust out while maintaining smooth rotation. The nylon cage reduces noise, making it ideal for household appliances like fans or blenders.

Industrial Uses of 6000-ZTN9/LT Bearing
In conveyor systems, 6000-ZTN9/LT Bearing handles radial loads efficiently, ensuring reliable performance in packaging or assembly lines. Its compact size fits neatly into tight spaces without sacrificing durability.

Where Is 6000-ZTN9/LT Bearing Used?
You’ll often find 6000-ZTN9/LT Bearing in office equipment like printers, where its low friction and quiet operation are key. The chrome steel construction also helps it last longer under daily wear and tear.

Built for Versatility: 6000-ZTN9/LT Bearing
6000-ZTN9/LT Bearing suits light-duty machinery, from power tools to small pumps, balancing speed and load capacity. The ABEC 1 tolerance ensures consistent performance without overcomplicating maintenance.

Automotive vs Industrial: Applications of 6000-ZTN9/LT Bearing
In cars, 6000-ZTN9/LT Bearing supports auxiliary units like alternators, while in factories, it keeps small gearboxes running smoothly. The metric sizing makes it a handy choice for global equipment standards.
