Single Row Deep Groove Ball Bearings 310SW1

Single Row Deep Groove Ball Bearings 310SW1

The 310SW1 is a single-row deep groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 14478 lbf and operates smoothly at speeds up to 7000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 1.15kg, it offers a robust build for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 310SW1
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 14478 lbf
  • Static Radial Load 11690 lbf
  • Max Speed 7000 rpm
  • Weight 1.15 kg
  • price（$） 62.037
Single Row Deep Groove Ball Bearings 310SW1 dimension drawing
Download DWG Download PDF

Features

Performance Features of 310SW1 Bearing

310SW1 Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.

Its dynamic radial load capacity reaches 14478 lbf, making it suitable for demanding applications.

The open design allows for easy lubrication, ensuring smooth operation and reduced maintenance.

With a maximum speed of 7,000 rpm, it balances performance and durability in various conditions.

Application

Industrial Uses of 310SW1 Bearing
310SW1 Bearing is commonly used in industrial machinery like pumps and electric motors, where its single row design handles radial loads efficiently. The open seal type makes it easy to lubricate and maintain in demanding environments.

In automotive applications, 310SW1 Bearing fits well in wheel hubs and transmission systems, providing reliable performance under varying speeds. Its chrome steel construction ensures durability even with frequent use.

For automation equipment, 310SW1 Bearing supports smooth operation in robotic arms and conveyor belts. The ABEC 1 tolerance class offers a good balance of precision and cost-effectiveness for these applications.

Where Is 310SW1 Bearing Used?
You’ll often find 310SW1 Bearing in household appliances like washing machines, where its radial load capacity handles the spinning drum. The wide temperature range also makes it suitable for different climates.

In light industrial settings, 310SW1 Bearing works well in gearboxes and small machinery. Its metric sizing ensures compatibility with a variety of equipment without needing modifications.
