Single Row Deep Groove Ball Bearings 310SG

Single Row Deep Groove Ball Bearings 310SG

The 310SG is a single-row deep groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 14478 lbf and operates smoothly at speeds reaching 7000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It suits applications like electric motors or pumps where radial loads are prevalent.

Weighing 1.15kg, it balances strength and manageability. Compliant with RoHS and REACH standards, it ensures safe usage in various environments.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 310SG
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 14478 lbf
  • Static Radial Load 11690 lbf
  • Max Speed 7000 rpm
  • Weight 1.15 kg
  • price（$） 17.946
Single Row Deep Groove Ball Bearings 310SG dimension drawing
Download DWG Download PDF

Features

Performance Features of 310SG Bearing

310SG Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 14478 lbf, ensuring reliable performance in various applications.
The single-row deep groove design provides smooth operation and reduces friction.
With a maximum speed of 7,000 rpm, it balances durability and efficiency.

Application

Industrial Uses of 310SG Bearing
The 310SG Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. Its open design allows for easy lubrication, making it suitable for high-speed applications.

Where Is 310SG Bearing Used?
You’ll often find the 310SG Bearing in automotive components such as alternators and wheel hubs, thanks to its durable chrome steel construction. Its metric sizing makes it a versatile choice for various vehicle models.

Perfect Fit for Automation: 310SG Bearing
In robotics and automation systems, the 310SG Bearing provides smooth operation in mechanical arms and conveyor belts. Its ABEC 1 tolerance ensures consistent performance in precision-driven tasks.

Medical vs Industrial: Where 310SG Bearing Excels
While the 310SG Bearing is robust enough for industrial gearboxes, it also meets the quiet operation needs of medical devices like centrifuges. The chrome steel cage adds longevity in both environments.

Consumer Electronics and the 310SG Bearing
For household appliances like washing machines, the 310SG Bearing offers quiet and efficient performance. Its wide temperature range makes it reliable even under varying load conditions.
