Single Row Deep Groove Ball Bearings 310SFF

Single Row Deep Groove Ball Bearings 310SFF

The 310SFF is a single-row deep groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 14478 lbf and operates smoothly at speeds reaching 7000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for applications like electric motors or pumps where radial loads are prevalent.

Weighing 1.15kg, it balances strength and manageability. Compliant with RoHS and REACH standards, it ensures safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 310SFF
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 14478 lbf
  • Static Radial Load 11690 lbf
  • Max Speed 7000 rpm
  • Weight 1.15 kg
  • price（$） 14.868
Single Row Deep Groove Ball Bearings 310SFF dimension drawing
Download DWG Download PDF

Features

How Does 310SFF Bearing Reduce Friction?

310SFF Bearing features a single row deep groove design, optimised for smooth radial load distribution.
The chrome steel construction ensures durability while minimising friction during operation.

With a dynamic radial load capacity of 14478 lbf, it handles demanding applications effortlessly.
Its ABEC 1 tolerance class guarantees consistent performance in various industrial settings.

The open seal design allows for easy maintenance and lubrication adjustments when needed.
Operating temperatures range from -30°C to 120°C, making it versatile for different environments.

Weighing just 1.15 kg, 310SFF Bearing offers a practical balance between strength and portability.
The 50 mm bore size provides a secure fit for medium-duty machinery and equipment.

Application

Common Applications of 310SFF Bearing
310SFF Bearing is widely used in industrial machinery, such as pumps and electric motors, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, making it suitable for high-speed applications.

In automotive systems, 310SFF Bearing can be found in wheel hubs and transmissions, providing reliable performance under varying loads. Its chrome steel construction offers durability in demanding conditions.

For automation equipment, 310SFF Bearing supports robotic arms and conveyor systems, where precision and longevity are key. The ABEC 1 tolerance ensures consistent performance in repetitive tasks.

In household appliances like washing machines, 310SFF Bearing helps reduce noise and vibration. Its metric sizing makes it a versatile choice for various consumer products.
