Single Row Deep Groove Ball Bearings 307MFF

Single Row Deep Groove Ball Bearings 307MFF

The 307MFF is a single-row deep groove ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel for durability. It handles radial loads up to 7801 lbf and operates smoothly at speeds up to 9500 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures reliable performance under stress. The bearing works efficiently in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or conveyor systems where radial loads are common.

Weighing 0.48kg, it’s a robust yet manageable option for various industrial uses. Compliant with RoHS and REACH standards, it’s safe for most environments.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 307MFF
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 21 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7801 lbf
  • Static Radial Load 5957 lbf
  • Max Speed 9500 rpm
  • Weight 0.48 kg
  • price（$） 13.761
Single Row Deep Groove Ball Bearings 307MFF dimension drawing
Download DWG Download PDF

Features

Performance Features of 307MFF Bearing

307MFF Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 7801 lbf, making it suitable for various industrial applications.
The open design ensures easy installation and maintenance, saving time and effort.
With a maximum speed of 9,500 rpm, it delivers reliable performance in demanding conditions.

Application

Common Applications of 307MFF Bearing
In industrial settings, 307MFF Bearing is commonly used in machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

Where Is 307MFF Bearing Used?
You’ll often find 307MFF Bearing in automotive applications such as alternators and wheel hubs, thanks to its durable chrome steel construction. Its metric sizing makes it a versatile choice for various vehicle models.

Ideal for Precision: 307MFF Bearing
For medical devices like centrifuges, 307MFF Bearing offers smooth operation due to its balanced radial load handling. The ABEC 1 tolerance ensures consistent performance in sensitive equipment.

Automotive vs Industrial: Applications of 307MFF Bearing
In automotive systems, 307MFF Bearing supports components like transmission shafts, while in industrial gearboxes, it handles high radial loads effortlessly. Its wide temperature range makes it suitable for diverse environments.

Practical Applications of 307MFF Bearing
In household appliances like washing machines, 307MFF Bearing provides quiet and efficient operation. The chrome steel cage enhances durability, making it a cost-effective choice for long-term use.
