Single Row Deep Groove Ball Bearings 217SZZ

Single Row Deep Groove Ball Bearings 217SZZ

The 217SZZ is a single-row deep groove ball bearing with an 85mm bore and 150mm outer diameter, crafted from sturdy chrome steel for durability. It manages radial loads up to 21762 lbf and operates smoothly at speeds up to 4800 RPM.

Shielded on both sides, it keeps contaminants out while maintaining smooth rotation. The chrome steel cage adds strength and longevity, suitable for demanding environments.

This bearing works well in temperatures from -30°C to 120°C, making it versatile for various settings. It’s interchangeable with SKF models, offering a reliable replacement option.

Ideal for industrial machinery or heavy equipment where radial load support is needed. Weighing 1.95kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 217SZZ
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 21762 lbf
  • Static Radial Load 22481 lbf
  • Max Speed 4800 rpm
  • Weight 1.95 kg
  • price（$） 60.021
Single Row Deep Groove Ball Bearings 217SZZ dimension drawing
Download DWG Download PDF

Features

Performance Features of 217SZZ Bearing

217SZZ Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 21762 lbf, ensuring reliable performance in various applications.

The shielded design of 217SZZ Bearing protects against contaminants, extending its service life.
With a maximum speed of 4,800 rpm, it balances durability and efficiency for smooth operation.

217SZZ Bearing operates in temperatures from -30°C to 120°C, making it suitable for diverse environments.
Its chrome steel cage ensures stability, reducing wear and maintaining alignment under load.

The ABEC 1 tolerance class of 217SZZ Bearing provides consistent performance for standard applications.
Its compact design, at 85 mm×150 mm×28 mm, makes it easy to integrate into various systems.

Application

Common Applications of 217SZZ Bearing
217SZZ Bearing is widely used in industrial machinery, especially in applications like pumps and electric motors where radial load support is essential. Its shielded design helps keep contaminants out, extending the lifespan in dusty environments.

In automotive systems, 217SZZ Bearing fits well in components such as alternators and wheel hubs, offering reliable performance under varying speeds. The chrome steel construction ensures durability even in demanding conditions.

For automation equipment, 217SZZ Bearing provides smooth operation in robotic arms and conveyor belts. Its ABEC 1 tolerance makes it suitable for applications requiring moderate precision.

In household appliances like washing machines, 217SZZ Bearing’s balanced design reduces noise and vibration. The wide temperature range allows it to perform consistently in different climates.

Medical devices such as centrifuges benefit from 217SZZ Bearing’s shielded protection and stable performance. The chrome steel cage adds extra resistance to wear in high-speed scenarios.
