Single Row Deep Groove Ball Bearings 212M

Single Row Deep Groove Ball Bearings 212M

The 212M is a single-row deep groove ball bearing with a 60mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 12612 lbf and operates smoothly at speeds up to 6700 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 0.85kg, it offers a good balance of strength and manageability. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 212M
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 22 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 12612 lbf
  • Static Radial Load 11240 lbf
  • Max Speed 6700 rpm
  • Weight 0.85 kg
  • price（$） 19.341
Single Row Deep Groove Ball Bearings 212M dimension drawing
Download DWG Download PDF

Features

Performance Features of 212M Bearing

212M Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 12612 lbf, ensuring reliable performance in various applications.

The single-row deep groove design of 212M Bearing allows for smooth operation and reduced friction.
With a maximum speed of 6,700 rpm, it balances efficiency and durability.

212M Bearing operates effectively in temperatures ranging from -30°C to 120°C.
Its open seal type simplifies maintenance while maintaining performance.

The chrome steel cage in 212M Bearing ensures proper ball alignment, extending its service life.
Its ABEC 1 tolerance class provides consistent performance for standard applications.

Application

Industrial Uses of 212M Bearing
212M Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

Where Is 212M Bearing Used?
You’ll often find 212M Bearing in automotive applications such as alternators and wheel hubs, thanks to its reliable performance under radial stress. Its metric sizing ensures compatibility with a variety of vehicle designs.

Built for Heavy-Duty Use: 212M Bearing
In automation systems, 212M Bearing supports robotic arms and conveyor belts, where its chrome steel construction ensures durability. The ABEC 1 tolerance class provides sufficient precision for most industrial tasks.

Medical vs Industrial: Where 212M Bearing Excels
While 212M Bearing isn’t typically used in medical devices, it shines in industrial settings like gearboxes and compressors. Its static radial load capacity makes it a dependable choice for heavy machinery.

Perfect Fit for Automation: 212M Bearing
For consumer electronics like washing machines, 212M Bearing offers smooth operation with minimal maintenance. The temperature range of -30°C to 120°C ensures reliability in various home environments.
