Single Row Deep Groove Ball Bearings 211MG

Single Row Deep Groove Ball Bearings 211MG

The 211MG is a single-row deep groove ball bearing with a 55mm bore and 100mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 10881 lbf and operates smoothly at speeds up to 7000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.66kg, it balances strength and lightness. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 211MG
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 21 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 10881 lbf
  • Static Radial Load 9892 lbf
  • Max Speed 7000 rpm
  • Weight 0.66 kg
  • price（$） 17.478
Single Row Deep Groove Ball Bearings 211MG dimension drawing
Download DWG Download PDF

Features

Performance Features of 211MG Bearing

211MG Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 10881 lbf.

Its single row deep groove design ensures smooth operation, making it suitable for various applications.

The open seal type allows for easy maintenance, while the chrome steel cage enhances durability.

With a maximum speed of 7,000 rpm, it balances performance and reliability in different conditions.

Application

Industrial Uses of 211MG Bearing
211MG Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, making it suitable for high-speed applications.

What Makes 211MG Bearing a Preferred Choice?
In automotive applications, 211MG Bearing fits well in wheel hubs and transmission systems, thanks to its durable chrome steel construction. Its metric sizing ensures compatibility with a variety of vehicle models.

Perfect Fit for Automation: 211MG Bearing
For automation equipment such as conveyor belts and robotic arms, 211MG Bearing offers smooth operation under consistent radial loads. The ABEC 1 tolerance class provides adequate precision for most industrial needs.

Medical vs Industrial: Where 211MG Bearing Excels
In medical devices like centrifuges, 211MG Bearing’s reliability and temperature resistance make it a practical choice. Meanwhile, in industrial settings, it handles heavy loads in machinery like gearboxes with ease.
