Single Row Deep Groove Ball Bearings 211/VE110

Single Row Deep Groove Ball Bearings 211/VE110

The 211/VE110 is a single-row deep groove ball bearing with a 55mm bore and 100mm outer diameter, crafted from sturdy chrome steel for lasting performance. It handles radial loads up to 10881 lbf and spins smoothly at speeds up to 7000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing operates reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing 0.66kg, it offers a solid balance of strength and manageability. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 211/VE110
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 21 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 10881 lbf
  • Static Radial Load 9892 lbf
  • Max Speed 7000 rpm
  • Weight 0.66 kg
Single Row Deep Groove Ball Bearings 211/VE110 dimension drawing
Download DWG Download PDF

Features

Performance Features of 211/VE110 Bearing

211/VE110 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 10881 lbf, ensuring reliable performance in various applications.

The single-row deep groove design enhances stability and reduces friction during operation.
With a maximum speed of 7,000 rpm, it balances durability and efficiency for long-term use.

211/VE110 Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its open seal design allows for easy maintenance and inspection when needed.

Application

Industrial Uses of 211/VE110 Bearing
211/VE110 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, extending its service life in demanding environments.

In automotive applications, 211/VE110 Bearing fits well in wheel hubs and transmission systems, providing reliable performance under varying speeds. Its metric dimensions make it a versatile choice for many vehicle models.

For automation equipment, 211/VE110 Bearing’s chrome steel construction offers durability in robotic arms and conveyor systems. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

Where Is 211/VE110 Bearing Used?
You’ll often find 211/VE110 Bearing in household appliances like washing machines, where its quiet operation and durability are key. The wide temperature range also makes it suitable for different climates.

In agricultural machinery, 211/VE110 Bearing handles radial loads in equipment like harvesters, thanks to its robust design. The chrome steel cage adds extra resistance to wear in dusty conditions.
