Single Row Deep Groove Ball Bearings 208MF

Single Row Deep Groove Ball Bearings 208MF

The 208MF is a single row deep groove ball bearing with a 40mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 7554 lbf and operates smoothly at speeds up to 9500 RPM.

Its open design simplifies maintenance, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.39kg, it balances strength and lightness. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 208MF
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 18 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7554 lbf
  • Static Radial Load 6070 lbf
  • Max Speed 9500 rpm
  • Weight 0.39 kg
  • price（$） 11.079
Single Row Deep Groove Ball Bearings 208MF dimension drawing
Download DWG Download PDF

Features

Performance Features of 208MF Bearing

208MF Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 7554 lbf, ensuring reliable performance in various applications.

The chrome steel cage maintains ball alignment, reducing friction and extending service life.
With a maximum speed of 9,500 rpm, it delivers a balance of durability and efficiency.

208MF Bearing operates smoothly in temperatures from -30° to 120°C, suitable for diverse environments.
Its open design simplifies installation and maintenance, saving time and effort.

The ABEC 1 tolerance class ensures consistent precision, making it ideal for standard industrial use.
Weighing just 0.39 kg, it combines strength with a lightweight design for easy handling.

Application

Industrial Uses of 208MF Bearing
208MF Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, making it suitable for high-speed applications.

In automotive systems, 208MF Bearing fits well in components such as alternators and wheel hubs, providing smooth operation under varying loads. Its metric sizing ensures compatibility with a wide range of vehicle models.

For automation equipment, 208MF Bearing supports precise movement in robotic arms and conveyor systems. The chrome steel construction offers durability, even in continuous operation.

Where Is 208MF Bearing Used?
You’ll often find 208MF Bearing in household appliances like washing machines and fans, where its quiet operation is a plus. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

Built for Heavy-Duty Use: 208MF Bearing
208MF Bearing handles radial loads effortlessly in construction equipment like small gearboxes. Its temperature range makes it adaptable to both indoor and outdoor environments.

Light-Duty vs Heavy-Duty: Best Uses for 208MF Bearing
In light-duty applications like office printers, 208MF Bearing offers longevity with minimal maintenance. For heavier tasks, it’s robust enough to handle industrial fans and compressors.
