Single Row Deep Groove Ball Bearings 16012/W64

Single Row Deep Groove Ball Bearings 16012/W64

The 16012/W64 is a single-row deep groove ball bearing with a 60mm bore and 95mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4474 lbf and runs smoothly at speeds up to 5400 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage adds durability. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative. Perfect for applications like electric motors or pumps where radial loads are common.

Weighing just 220g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 16012/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 95 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 11 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4474 lbf
  • Static Radial Load 3934 lbf
  • Max Speed 5400 rpm
  • Weight 220 g
  • price（$） 24.93
Single Row Deep Groove Ball Bearings 16012/W64 dimension drawing
Download DWG Download PDF

Features

Performance Features of 16012/W64 Bearing

16012/W64 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 4474 lbf, ensuring reliable performance in various applications.

The solid oil lubrication reduces friction and extends maintenance intervals.
With a maximum speed of 5,400 rpm, it balances durability and efficiency.

16012/W64 Bearing operates smoothly in temperatures from -30°C to 120°C.
Its open design allows for easy inspection and maintenance.

Application

Common Applications of 16012/W64 Bearing
16012/W64 Bearing is widely used in industrial machinery, such as pumps and electric motors, where its radial load capacity ensures reliable performance. The solid oil lubrication reduces maintenance needs, making it suitable for continuous operation.

In automotive applications, 16012/W64 Bearing fits well in components like alternators and fans, providing smooth rotation under varying speeds. Its chrome steel construction offers durability in both high and low-temperature conditions.

For automation systems, 16012/W64 Bearing supports precise movements in robotic arms and conveyor belts. The open design allows for easy inspection and cleaning, which is handy in dusty environments.

You’ll also find 16012/W64 Bearing in household appliances like washing machines, where its quiet operation and long lifespan are appreciated. The metric sizing ensures compatibility with a range of European and Asian brands.
