Single Row Cylindrical Roller Thrust Bearings 811/560 M

Single Row Cylindrical Roller Thrust Bearings 811/560 M

The 811/560 M is a single-row cylindrical roller thrust bearing with a 560mm bore and 670mm outer diameter, built from sturdy chrome steel. It handles heavy thrust loads up to 396000 lbf and operates smoothly at speeds up to 500 RPM.

Its machined brass cage ensures durability, while the precise tolerances provide reliable performance. The bearing works well in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial machinery or large gearboxes where high thrust loads are common.

Weighing 58kg, it’s designed for robust performance in demanding environments. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 811/560 M
  • size 560 mm x 670 mm x 85 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 1
  • Bore Dia 560 mm
  • Bore Dia Tolerance -0.050mm to 0
  • Outer Dia 670 mm
  • Outer Dia Tolerance -0.075mm to 0
  • Width 85 mm
  • Height Tolerance -0.60mm to +0.06mm
  • Outside Diameter Shaft Washer 665 mm
  • Bore Diameter Housing Washer 565 mm
  • Height Shaft Washer 25.5 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 3 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 396000 lbf
  • Static Radial Load 2475000 lbf
  • Max Speed 500 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 58 kg
  • Roller And Cage Thrust Assembly K-811/560 M
  • Shaft Washer IW-811/560
  • Housing Washer OW-811/560
Single Row Cylindrical Roller Thrust Bearings 811/560 M dimension drawing
Download DWG Download PDF

Features

Performance Features of 811/560 M Bearing

811/560 M Bearing is built with chrome steel washers and rollers, offering robust resistance to heavy thrust loads.
Its dynamic radial load capacity reaches 396000 lbf, ensuring dependable performance in industrial applications.
The machined brass cage maintains roller alignment, reducing friction and enhancing durability.
With a maximum speed of 500 rpm, it delivers stability under high-load conditions.

How Is 811/560 M Bearing Engineered for Reliability?

811/560 M Bearing’s precise cylindrical roller design ensures even load distribution, minimising wear.
The chrome steel construction provides excellent resistance to wear and corrosion.
Its large bore diameter of 560 mm makes it suitable for heavy machinery applications.
The bearing operates efficiently within a temperature range of -30° to 110 °C.

Built for Durability: 811/560 M Bearing

811/560 M Bearing features a machined brass cage that withstands high stress and reduces vibration.
Its static radial load capacity of 2475000 lbf makes it ideal for demanding environments.
The bearing’s chamfered housing washer design allows for easier installation and alignment.
Weighing 58 kg, it is designed for stability in large-scale industrial equipment.

Steel vs Ceramic Bearings: Strengths of 811/560 M Bearing

811/560 M Bearing uses chrome steel for both rollers and washers, ensuring high load capacity and durability.
This material choice provides better resistance to impact compared to ceramic alternatives.
The bearing’s brass cage offers superior heat dissipation in high-load scenarios.
Its metric dimensions (560 mm x 670 mm x 85 mm) make it compatible with standard industrial equipment.

Why Choose 811/560 M Bearing for Precision Tasks?

811/560 M Bearing’s single-row cylindrical roller design ensures precise load handling in thrust applications.
The tight tolerances on bore and outer diameters (-0.050mm to 0 and -0.075mm to 0) guarantee accurate performance.
Its machined brass cage reduces noise during operation, making it suitable for precision machinery.
The bearing maintains consistent performance across its -30° to 110 °C temperature range.

Application

Industrial Uses of 811/560 M Bearing
811/560 M Bearing is commonly used in heavy machinery like hydraulic presses and large gearboxes, where its cylindrical roller design efficiently handles high thrust loads. The machined brass cage ensures smooth operation even under demanding conditions.

Where Is 811/560 M Bearing Used?
You’ll find 811/560 M Bearing in wind turbine systems, supporting the main shaft where reliability is key. Its chrome steel construction offers excellent durability in harsh outdoor environments.

Built for Heavy-Duty Use: 811/560 M Bearing
811/560 M Bearing excels in mining equipment, such as crushers and conveyors, thanks to its robust design and high static load capacity. The precise tolerances make it a dependable choice for critical applications.

Automotive vs Aerospace: Applications of 811/560 M Bearing
In automotive, 811/560 M Bearing is used in large truck transmissions, while in aerospace, it supports landing gear mechanisms. Its metric sizing ensures compatibility with a variety of international standards.

Essential Roles of 811/560 M Bearing
811/560 M Bearing plays a vital role in steel mills, where it withstands extreme loads in rolling mills. The temperature range of -30° to 110°C makes it suitable for both hot and cold environments.
