Single Row Cylindrical Roller Bearings With Inner Ring NUP 2216 ECP

Single Row Cylindrical Roller Bearings With Inner Ring NUP 2216 ECP

The NUP 2216 ECP is a single row cylindrical roller bearing with an 80mm bore and 140mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 47700 lbf and operates smoothly at speeds up to 6000 RPM.

Its PA66 cage keeps rollers centred for consistent performance, while the open design allows easy lubrication with grease or oil. The bearing works well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery or heavy equipment where radial and axial loads are present.

Weighing 2.02kg, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NUP 2216 ECP
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.15mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 33 mm
  • Width Tolerance -0.15mm to 0
  • Shoulder Dia Of Inner Ring 101 mm
  • Chamfer Dimension r1,2(min.) 2 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 47700 lbf
  • Static Radial Load 55125 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6000 rpm
  • Weight 2.02 kg
  • Shoulder Dia Of Outer Ring 121.7 mm
  • Raceway Diameter Of Inner Ring 95.3 mm
  • Chamfer Dimension Of Loose Flange Ring(r3,4)(min.) 2 mm
Single Row Cylindrical Roller Bearings With Inner Ring NUP 2216 ECP dimension drawing
Download DWG Download PDF

Features

Why Choose NUP 2216 ECP Bearing for Precision Tasks?

NUP 2216 ECP Bearing features a single-row cylindrical roller design, ideal for handling combined radial and axial loads.
Its chrome steel construction ensures durability and resistance to wear, even under high dynamic radial loads of 47,700 lbf.
The PA66 cage keeps rollers centred, promoting smooth operation at speeds up to 6,000 rpm.
With a temperature range of -30° to 110°C, it performs reliably in various environments.

Application

Industrial Uses of NUP 2216 ECP Bearing
NUP 2216 ECP Bearing is commonly used in heavy machinery like gearboxes and industrial pumps, where its cylindrical roller design handles both radial and axial loads efficiently. The chrome steel construction ensures durability in demanding environments.

Where Is NUP 2216 ECP Bearing Used?
You’ll often find NUP 2216 ECP Bearing in conveyor systems and electric motors, thanks to its high-speed capability and reliable performance. The open seal design allows for easy lubrication, making maintenance straightforward.

Built for Heavy-Duty Use: NUP 2216 ECP Bearing
NUP 2216 ECP Bearing excels in applications like crane hooks and rolling mills, where combined loads are frequent. Its PA66 cage provides stability and reduces friction during high-speed operations.

Automotive vs Aerospace: Applications of NUP 2216 ECP Bearing
In automotive transmissions, NUP 2216 ECP Bearing supports smooth gear shifts, while in aerospace, it’s valued for its precision in auxiliary systems. The metric sizing ensures compatibility across various industries.

Perfect Fit for Automation: NUP 2216 ECP Bearing
NUP 2216 ECP Bearing is ideal for robotic arms and automated assembly lines, where consistent performance is key. The grease or oil lubrication options adapt to different operational needs.
