Single Row Cylindrical Roller Bearings With Inner Ring NU 360 ECM

Single Row Cylindrical Roller Bearings With Inner Ring NU 360 ECM

The NU 360 ECM is a single row cylindrical roller bearing with a 300mm bore and 620mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 524250 lbf and runs smoothly at speeds up to 1000 RPM.

Its brass cage keeps rollers centred for even load distribution, while the open design allows easy lubrication with grease or oil. The bearing operates well in temperatures from -30°C to 110°C.

With a 109mm width and 7.5mm chamfer, it fits securely in heavy-duty setups. This model is interchangeable with SKF bearings, making it a practical choice for replacements.

Ideal for industrial machinery like gearboxes or large motors where high radial loads are common. Compliant with RoHS and REACH standards, it’s a reliable option for demanding environments. Weighing 174kg, it’s built for durability.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 360 ECM
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 300 mm
  • Bore Dia Tolerance -0.035mm to 0
  • Outer Dia 620 mm
  • Outer Dia Tolerance -0.05mm to 0
  • Width 109 mm
  • Width Tolerance -0.35mm to 0
  • Chamfer Dimension r1,2(min.) 7.5 mm
  • Permissible Axial Displacement(max.) 4 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass cage, roller centred
  • Dynamic Radial Load 524250 lbf
  • Static Radial Load 753750 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 1000 rpm
  • Weight 174 kg
  • Shoulder Dia Of Outer Ring 505 mm
  • Raceway Diameter Of Inner Ring 385 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 360 ECM dimension drawing
Download DWG Download PDF

Features

How Does NU 360 ECM Bearing Handle Combined Loads?

NU 360 ECM Bearing is built with chrome steel rings and rollers, offering robust resistance to both radial and axial loads.
Its dynamic radial load capacity reaches 524,250 lbf, ensuring reliable performance in heavy-duty applications.
The brass cage keeps the rollers centred, reducing friction and extending operational life.
With a maximum speed of 1,000 rpm, it delivers durability and efficiency in demanding conditions.

Application

Industrial Uses of NU 360 ECM Bearing
NU 360 ECM Bearing is commonly used in heavy machinery like paper mills and mining equipment, where its robust design handles high radial loads effortlessly. The brass cage ensures smooth operation even in demanding conditions.

Where Is NU 360 ECM Bearing Used?
You’ll often find NU 360 ECM Bearing in wind turbines and large industrial gearboxes, thanks to its ability to withstand combined loads. Its chrome steel construction offers durability in harsh environments.

Built for Heavy-Duty Use: NU 360 ECM Bearing
NU 360 ECM Bearing excels in steel production lines, where its single-row cylindrical design manages heavy radial forces. The open seal type allows for easy lubrication, extending its service life.

Automotive vs Aerospace: Applications of NU 360 ECM Bearing
In automotive applications, NU 360 ECM Bearing supports large drivetrain components, while in aerospace, it’s used in auxiliary systems. Its metric sizing ensures compatibility across industries.

Practical Applications of NU 360 ECM Bearing
NU 360 ECM Bearing is ideal for conveyor systems in logistics hubs, where its high dynamic load capacity keeps operations running smoothly. The grease lubrication option reduces maintenance needs.
