Single Row Cylindrical Roller Bearings With Inner Ring NU 2217 ECPH

Brand: TFL Bearing Interchangeable: SKF NU 2217 ECPH 85 mm × 150 mm × 36 mm Metric Open
Part number: NU 2217 ECPH
Single Row Cylindrical Roller Bearings With Inner Ring NU 2217 ECPH
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia85 mm
Bore Dia Tolerance-0.02mm to 0
Outer Dia150 mm
Outer Dia Tolerance-0.018mm to 0
Width36 mm
Width Tolerance-0.20mm to 0
Chamfer Dimension r1,2(min.)2 mm
Chamfer Dimension r3,4(min.)2 mm
Shoulder Dia Of Outer Ring130.3 mm
Raceway Diameter Of Inner Ring100.5 mm
Performance
Dynamic Radial Load56,250 lbf
Static Radial Load63,000 lbf
Temperature Range-30° to 110 °C
Max Speed5,000 rpm
Characteristics
Permissible Axial Displacement(max.)2 mm
System of MeasurementMetric
Roller Bearing TypeCylindrical
For Load DirectionCombined
ConstructionSingle Row
Inner Ring TypeWith Inner Ring
Seal TypeOpen
LubricationGrease, Oil
Weight2.49 kg
Material
Ring MaterialChrome Steel
Roller MaterialChrome Steel
Cage MaterialPEEK cage, roller centred
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The NU 2217 ECPH is a single row cylindrical roller bearing with an 85mm bore and 150mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 56250 lbf and operates smoothly at speeds up to 5000 RPM.

Its PEEK cage keeps rollers centred for even load distribution, while the open design allows easy lubrication with grease or oil. The bearing performs well in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial gearboxes or machinery where radial and axial loads are present.

Weighing 2.49kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and reliable use.

Features

Performance Features of NU 2217 ECPH Bearing

NU 2217 ECPH Bearing is designed with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 56250 lbf, ensuring reliable performance in demanding applications.

The PEEK cage keeps the rollers centred, reducing wear and extending service life.
With a maximum speed of 5000 rpm, it balances durability and efficiency.

NU 2217 ECPH Bearing works in temperatures from -30° to 110°C, making it suitable for various environments.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.

The precise chamfer dimensions of 2 mm ensure smooth installation and operation.
This bearing is ideal for applications requiring high radial load capacity and long service life.

Application

Industrial Uses of NU 2217 ECPH Bearing
NU 2217 ECPH Bearing is commonly used in heavy machinery like gearboxes and large electric motors, where its cylindrical roller design handles high radial loads efficiently.
The PEEK cage ensures smooth operation at high speeds, making it suitable for industrial applications requiring durability and precision.

Where Is NU 2217 ECPH Bearing Used?
NU 2217 ECPH Bearing finds its place in conveyor systems and printing presses, thanks to its ability to manage combined loads.
Its chrome steel construction and open design make it easy to maintain, even in demanding environments.

Built for Heavy-Duty Use: NU 2217 ECPH Bearing
NU 2217 ECPH Bearing excels in applications like wind turbines and mining equipment, where reliability under heavy loads is essential.
The wide temperature range and compatibility with both grease and oil lubrication add to its versatility.

Automotive vs Industrial: Applications of NU 2217 ECPH Bearing
In automotive settings, NU 2217 ECPH Bearing supports components like drivetrains, while in industrial settings, it’s ideal for pumps and compressors.
Its metric sizing and high dynamic load capacity make it a flexible choice across sectors.
