Single Row Cylindrical Roller Bearings With Inner Ring NU 1034 ML

Single Row Cylindrical Roller Bearings With Inner Ring NU 1034 ML

The NU 1034 ML is a single row cylindrical roller bearing with a 170mm bore and 260mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 72000 lbf and operates smoothly at speeds up to 4000 RPM.

Its brass cage design ensures durability, while the open seal allows for easy lubrication with grease or oil. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial machinery or gear systems where robust performance is needed.

Weighing 7.99kg, it’s built to last while maintaining precision. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 1034 ML
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 170 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 260 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 42 mm
  • Width Tolerance -0.25mm to 0
  • Chamfer Dimension r1,2(min.) 2.1 mm
  • Chamfer Dimension r3,4(min.) 2.1 mm
  • Permissible Axial Displacement(max.) 5.8 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass cage, inner or outer ring centred
  • Dynamic Radial Load 72000 lbf
  • Static Radial Load 90000 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4000 rpm
  • Weight 7.99 kg
  • Shoulder Dia Of Outer Ring 226.9 mm
  • Raceway Diameter Of Inner Ring 193 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 1034 ML dimension drawing
Download DWG Download PDF

Features

Performance Features of NU 1034 ML Bearing

NU 1034 ML Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 72,000 lbf, ensuring reliable performance in heavy-duty applications.

The brass cage design keeps the rollers aligned, reducing friction and extending service life.
With a maximum speed of 4,000 rpm, it balances durability and efficiency for various industrial uses.

NU 1034 ML Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.

The precise chamfer dimensions of 2.1 mm ensure easy installation and alignment.
This bearing is interchangeable with SKF models, providing flexibility in replacements.

Application

Industrial Uses of NU 1034 ML Bearing
NU 1034 ML Bearing is commonly used in heavy machinery like industrial gearboxes and large pumps, where its cylindrical roller design handles high radial loads efficiently. The brass cage ensures smooth operation even at speeds up to 4000 rpm.

Where Is NU 1034 ML Bearing Used?
You’ll find NU 1034 ML Bearing in conveyor systems and mining equipment, thanks to its robust chrome steel construction. Its open design allows for easy lubrication, making it ideal for harsh environments.

Perfect Fit for Automation: NU 1034 ML Bearing
NU 1034 ML Bearing works well in automated production lines, particularly in robotic arms and assembly systems. The combined load capability ensures reliable performance under varying operational stresses.

Automotive vs Aerospace: Applications of NU 1034 ML Bearing
In automotive applications, NU 1034 ML Bearing supports drivetrain components like axles and transmissions. For aerospace, its precision and durability make it suitable for auxiliary power units and landing gear systems.
