Single Row Cylindrical Roller Bearings With Inner Ring NU 1009 ECPH

Single Row Cylindrical Roller Bearings With Inner Ring NU 1009 ECPH

The NU 1009 ECPH is a single-row cylindrical roller bearing with a 45mm bore and 75mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 11700 lbf and reaches speeds of 11000 RPM.

Its PEEK cage keeps rollers centred for smooth operation, while the open design allows easy lubrication with grease or oil. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial and axial loads are present.

Weighing just 0.25kg, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 1009 ECPH
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 75 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • Chamfer Dimension r1,2(min.) 1 mm
  • Chamfer Dimension r3,4(min.) 0.6 mm
  • Permissible Axial Displacement(max.) 0.9 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PEEK cage, roller centred
  • Dynamic Radial Load 11700 lbf
  • Static Radial Load 11700 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 0.25 kg
  • Shoulder Dia Of Outer Ring 65.3 mm
  • Raceway Diameter Of Inner Ring 52.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 1009 ECPH dimension drawing
Download DWG Download PDF

Features

How Does NU 1009 ECPH Bearing Handle Combined Loads?

NU 1009 ECPH Bearing features a chrome steel construction, offering strong resistance to both radial and axial loads.
Its dynamic radial load capacity reaches 11700 lbf, ensuring reliable performance in various applications.
The PEEK cage keeps the rollers centred, reducing wear and extending service life.
With a maximum speed of 11000 rpm, it balances durability and efficiency.

Application

Industrial Uses of NU 1009 ECPH Bearing
NU 1009 ECPH Bearing is commonly used in industrial machinery like conveyor systems and gearboxes, where its cylindrical roller design handles combined loads efficiently. The open seal type allows for easy lubrication, making it suitable for high-speed operations up to 11000 rpm.

Where Is NU 1009 ECPH Bearing Used?
In automotive applications, NU 1009 ECPH Bearing supports components such as transmissions and differentials, thanks to its durable chrome steel construction. The PEEK cage ensures smooth performance even under heavy radial loads.

Built for Heavy-Duty Use: NU 1009 ECPH Bearing
NU 1009 ECPH Bearing excels in automation equipment like robotic arms, where precise axial displacement is required. Its metric sizing and grease lubrication make it a reliable choice for various industrial settings.

Medical vs Industrial: Where NU 1009 ECPH Bearing Excels
NU 1009 ECPH Bearing is ideal for medical imaging devices, offering consistent performance with its chrome steel rollers. In industrial settings, it’s favoured for its ability to withstand high dynamic radial loads.

Perfect Fit for Automation: NU 1009 ECPH Bearing
NU 1009 ECPH Bearing is often found in 3D printers and CNC machines, where its single-row design ensures accuracy. The temperature range of -30° to 110°C makes it versatile for different environments.
