Single Row Cylindrical Roller Bearings With Inner Ring NJ 2206 ECP

Single Row Cylindrical Roller Bearings With Inner Ring NJ 2206 ECP

The NJ 2206 ECP is a single-row cylindrical roller bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 12375 lbf and reaches speeds of 14000 RPM.

Its open design allows for easy lubrication with grease or oil, while the PA66 cage ensures smooth operation. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for machinery requiring high-speed performance and combined load handling, such as gearboxes or pumps.

Weighing just 0.26kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NJ 2206 ECP
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • Shoulder Dia Of Inner Ring 41.2 mm
  • Chamfer Dimension r1,2(min.) 1 mm
  • Chamfer Dimension r3,4(min.) 0.6 mm
  • Permissible Axial Displacement(max.) 1.8 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 12375 lbf
  • Static Radial Load 11025 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 14000 rpm
  • Weight 0.26 kg
  • Shoulder Dia Of Outer Ring 51.95 mm
  • Raceway Diameter Of Inner Ring 37.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NJ 2206 ECP dimension drawing
Download DWG Download PDF

Features

How Does NJ 2206 ECP Bearing Handle Combined Loads?

NJ 2206 ECP Bearing is built with chrome steel rings and rollers, offering strong resistance to both radial and axial loads.
Its dynamic radial load capacity reaches 12,375 lbf, ensuring reliable performance in demanding conditions.
The PA66 cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 14,000 rpm, it balances durability and efficiency in high-speed applications.

Application

Industrial Uses of NJ 2206 ECP Bearing
NJ 2206 ECP Bearing is commonly used in machine tools, where its cylindrical roller design handles both radial and axial loads efficiently. The chrome steel construction ensures durability in high-speed operations.

In automotive applications, NJ 2206 ECP Bearing fits well in gearboxes and transmissions, providing smooth performance under combined loads. Its metric sizing makes it a versatile choice for various vehicle models.

For automation systems, NJ 2206 ECP Bearing supports robotic arms and conveyor belts, thanks to its high-speed capability and reliable PA66 cage. The open design allows for easy lubrication and maintenance.

Where Is NJ 2206 ECP Bearing Used?
You’ll find NJ 2206 ECP Bearing in industrial fans and pumps, where its robust design handles continuous operation. The temperature range of -30° to 110°C makes it suitable for diverse environments.

In household appliances like washing machines, NJ 2206 ECP Bearing ensures quiet and efficient performance. Its grease or oil lubrication options provide flexibility for different maintenance needs.
