Single Row Angular Contact Ball Bearings (General) 7315 BEGAP

Single Row Angular Contact Ball Bearings (General) 7315 BEGAP

The 7315 BEGAP is a single-row angular contact ball bearing with a 75mm bore and 160mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 29700 lbf and operates smoothly at speeds up to 5300 RPM.

With a 40° contact angle, it efficiently manages combined radial and axial loads. The open design and nylon cage ensure durability while allowing easy lubrication.

This bearing suits applications like pumps or gearboxes where precise alignment is needed. It’s interchangeable with SKF models, making replacements straightforward.

Weighing 3.2kg, it’s robust yet manageable. Compliant with RoHS and REACH standards, it works in temperatures from -30°C to 110°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7315 BEGAP
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 75 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 160 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 37 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 108.25 mm
  • External Diameter On Inner Ring (Small Side Face) 91.13 mm
  • Internal Diameter On Outer Ring 128.9 mm
  • Chamfer Dimension 2.1 mm
  • Distance Pressure Point (a) 68 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 29700 lbf
  • Static Radial Load 23400 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 5300 rpm
  • Weight 3.2 kg
  • Price（$） 78.58
Single Row Angular Contact Ball Bearings (General) 7315 BEGAP dimension drawing
Download DWG Download PDF

Features

Performance Features of 7315 BEGAP Bearing

7315 BEGAP Bearing is built with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.

The nylon cage in 7315 BEGAP Bearing reduces friction and noise, enhancing smooth operation.
With a dynamic radial load capacity of 29,700 lbf, it performs reliably under heavy loads.

7315 BEGAP Bearing operates efficiently within a temperature range of -30° to 110°C.
Its P6 tolerance class (ABEC-3) ensures precision and consistent performance.

Application

Industrial Uses of 7315 BEGAP Bearing
The 7315 BEGAP Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. Its open design and nylon cage make it suitable for high-speed operations in industrial settings.

Where Is 7315 BEGAP Bearing Used?
You’ll often find 7315 BEGAP Bearing in automotive applications like wheel hubs and transmissions, thanks to its robust chrome steel construction. The P6 tolerance ensures reliable performance even under demanding conditions.

Built for Heavy-Duty Use: 7315 BEGAP Bearing
In conveyor systems, 7315 BEGAP Bearing excels due to its ability to manage heavy loads and maintain stability. The lubricated design helps reduce friction, extending the bearing’s service life.

Automotive vs Aerospace: Applications of 7315 BEGAP Bearing
While 7315 BEGAP Bearing is popular in car transmissions, it’s also used in aerospace equipment for its precision and durability. The metric sizing makes it versatile across different industries.

Perfect Fit for Automation: 7315 BEGAP Bearing
In robotic arms, 7315 BEGAP Bearing provides smooth movement and precise positioning. Its nylon cage reduces noise, making it ideal for automated production lines.
