Single Row Angular Contact Ball Bearings (General) 7314 BECBM

Single Row Angular Contact Ball Bearings (General) 7314 BECBM

The 7314 BECBM is a single-row angular contact ball bearing with a 70mm bore and 150mm outer diameter, crafted from sturdy chrome steel. Its 40° contact angle efficiently manages combined radial and axial loads, supporting up to 28575 lbf dynamically.

The brass cage enhances durability, while the open design allows for straightforward lubrication. It operates smoothly at speeds up to 7000 RPM and handles temperatures from -30°C to 110°C.

With a P6 tolerance class, it offers reliable precision for demanding applications. This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for gearboxes, pumps, or industrial machinery where angular contact performance is key.

Weighing 2.65kg, it balances strength and manageability. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7314 BECBM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 35 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 101.1 mm
  • External Diameter On Inner Ring (Small Side Face) 84.4 mm
  • Internal Diameter On Outer Ring 121.5 mm
  • Chamfer Dimension 2.1 mm
  • Distance Pressure Point (a) 64 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 28575 lbf
  • Static Radial Load 22050 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 7000 rpm
  • Weight 2.65 kg
  • Price（$） 64.75
Single Row Angular Contact Ball Bearings (General) 7314 BECBM dimension drawing
Download DWG Download PDF

Features

Performance Features of 7314 BECBM Bearing

7314 BECBM Bearing is built with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel rings and balls provide strong resistance to wear, ensuring long-term reliability.

The brass cage maintains ball alignment, reducing friction and enhancing smooth operation.
With a dynamic radial load capacity of 28,575 lbf, it performs well in demanding applications.

7314 BECBM Bearing operates efficiently at speeds up to 7,000 rpm, balancing speed and durability.
Its P6 tolerance class ensures precision, making it suitable for high-performance machinery.

Application

Industrial Uses of 7314 BECBM Bearing
The 7314 BECBM Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. Its brass cage ensures smooth operation even at high speeds, making it suitable for precision machining.

In automotive applications, 7314 BECBM Bearing supports gearboxes and wheel hubs, providing reliable performance under heavy loads. The chrome steel construction enhances durability, ensuring long service life in demanding conditions.

For automation systems, 7314 BECBM Bearing is ideal for robotic arms and conveyor belts, offering stability and precision. Its open design allows for easy lubrication, reducing maintenance downtime in continuous operations.

Medical imaging devices benefit from 7314 BECBM Bearing’s consistent performance and low noise levels. The P6 tolerance class ensures high accuracy, crucial for sensitive diagnostic equipment.

In household appliances like washing machines, 7314 BECBM Bearing provides quiet and efficient operation. Its robust design handles the vibrations and loads typical in daily use, ensuring reliability over time.
