Single Row Angular Contact Ball Bearings (General) 7314 ACCBM

Brand: TFL Bearing Interchangeable: SKF 7314 ACCBM 70 mm × 150 mm × 35 mm Metric Open
Part number: 7314 ACCBM
Single Row Angular Contact Ball Bearings (General) 7314 ACCBM
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia70 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia150 mm
Outer Dia Tolerance-0.015mm to 0
Width35 mm
Width Tolerance-0.05mm to 0
External Diameter On Inner Ring (Large Side Face)100.94 mm
External Diameter On Inner Ring (Small Side Face)84.4 mm
Internal Diameter On Outer Ring120.43 mm
Chamfer Dimension2.1 mm
Performance
Dynamic Radial Load32,175 lbf
Static Radial Load24,750 lbf
Temperature Range-30° to 110 °C
Max Speed8,500 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Contact Angle25°
For Load DirectionAngular Contact
ConstructionSingle Row
Seal TypeOpen
Distance Pressure Point (a)43 mm
LubricationLubricated
Tolerance ClassP6 (ABEC-3)
Weight2.65 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialBrass
Compliance
ROHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 7314 ACCBM is a single-row angular contact ball bearing with a 70mm bore and 150mm outer diameter, crafted from sturdy chrome steel. Its 25° contact angle efficiently manages combined radial and axial loads.

This bearing supports dynamic radial loads up to 32175 lbf and spins smoothly at speeds reaching 8500 RPM. The brass cage enhances durability while reducing friction during operation.

Its open design simplifies lubrication, and the P6 tolerance class ensures precise performance. Suitable for temperatures between -30°C and 110°C, it’s versatile for various conditions.

Ideal for machinery like pumps or gearboxes where angular loads are common. Weighing 2.65kg, it’s robust yet manageable for industrial use. Compliant with RoHS and REACH standards for safety.

Features

Performance Features of 7314 ACCBM Bearing

7314 ACCBM Bearing features a 25° contact angle, optimised for handling combined radial and axial loads.
Its chrome steel construction ensures durability, while the brass cage maintains ball alignment for smooth operation.

The bearing’s dynamic radial load capacity of 32175 lbf makes it suitable for demanding applications.
With a maximum speed of 8,500 rpm, it delivers reliable performance in high-speed scenarios.

Designed for a temperature range of -30° to 110°C, 7314 ACCBM Bearing adapts to various operating conditions.
Its P6 tolerance class (ABEC-3) ensures precision and consistent performance.

Application

Industrial Uses of 7314 ACCBM Bearing
7314 ACCBM Bearing is commonly used in machine tools, where its angular contact design handles combined radial and axial loads efficiently. The brass cage ensures smooth operation at high speeds, making it suitable for precision machining.

Where Is 7314 ACCBM Bearing Used?
In automotive applications, 7314 ACCBM Bearing supports wheel hubs and gearboxes, thanks to its durable chrome steel construction. The 25° contact angle provides stability under varying load conditions.

Built for Heavy-Duty Use: 7314 ACCBM Bearing
For conveyor systems, 7314 ACCBM Bearing offers reliable performance in heavy-load environments. Its open design allows for easy lubrication, extending service life in demanding industrial settings.

Automotive vs Aerospace: Applications of 7314 ACCBM Bearing
In aerospace, 7314 ACCBM Bearing is favoured for its high-speed capabilities and precision. Meanwhile, automotive applications benefit from its robustness in gearbox and drivetrain systems.

Perfect Fit for Automation: 7314 ACCBM Bearing
7314 ACCBM Bearing is ideal for robotic arms, where its angular contact design ensures accurate movement. The P6 tolerance class guarantees consistent performance in automated production lines.
