Single Row Angular Contact Ball Bearings (General) 7313 BEGBM

Brand: TFL Bearing Interchangeable: SKF 7313 BEGBM 65 mm × 140 mm × 33 mm Metric Open
Part number: 7313 BEGBM
Single Row Angular Contact Ball Bearings (General) 7313 BEGBM
In Stock
US$55.23 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia65 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia140 mm
Outer Dia Tolerance-0.015mm to 0
Width33 mm
Width Tolerance-0.05mm to 0
External Diameter On Inner Ring (Large Side Face)94.15 mm
External Diameter On Inner Ring (Small Side Face)78.45 mm
Internal Diameter On Outer Ring112.85 mm
Chamfer Dimension2.1 mm
Performance
Dynamic Radial Load26,100 lbf
Static Radial Load19,462 lbf
Temperature Range-30° to 110 °C
Max Speed8,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Contact Angle40°
For Load DirectionAngular Contact
ConstructionSingle Row
Seal TypeOpen
Distance Pressure Point (a)60 mm
LubricationLubricated
Tolerance ClassP6 (ABEC-3)
Weight2.15 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialBrass
Compliance
ROHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 7313 BEGBM is a single-row angular contact ball bearing with a 65mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 26100 lbf and operates smoothly at speeds up to 8000 RPM.

With a 40° contact angle, it efficiently handles combined radial and axial loads. The brass cage enhances durability, while the open design simplifies lubrication and maintenance.

This bearing suits applications like pumps or gearboxes where angular loads are common. Its P6 tolerance class ensures reliable precision in demanding conditions.

Weighing 2.15kg, it’s robust yet manageable for industrial use. Compliant with RoHS and REACH standards, it’s a safe choice for various environments.

Features

Performance Features of 7313 BEGBM Bearing

7313 BEGBM Bearing is designed with a 40° contact angle, optimising load distribution for angular contact applications.
Its chrome steel rings and balls ensure durability under dynamic radial loads up to 26100 lbf.

The brass cage maintains ball alignment, reducing friction and enhancing operational smoothness.
With a maximum speed of 8,000 rpm, it delivers reliable performance in various conditions.

7313 BEGBM Bearing operates efficiently within a temperature range of -30° to 110°C.
Its P6 tolerance class ensures precision, making it suitable for high-performance machinery.

Application

Industrial Uses of 7313 BEGBM Bearing
The 7313 BEGBM Bearing is commonly used in machine tools, where its angular contact design efficiently handles combined radial and axial loads. Its brass cage ensures smooth operation even at higher speeds, making it suitable for precision machining.

In automotive applications, 7313 BEGBM Bearing supports gearboxes and wheel hubs, providing reliable performance under varying loads. The 40° contact angle enhances stability, which is crucial for vehicle safety and longevity.

For robotics, 7313 BEGBM Bearing is a solid choice for joints and rotating parts due to its balanced load capacity. The open design allows for easy lubrication, ensuring minimal downtime in automated systems.

Medical imaging devices benefit from 7313 BEGBM Bearing’s consistent performance and low noise levels. The chrome steel construction ensures durability, even in high-precision diagnostic equipment.

In household appliances like washing machines, 7313 BEGBM Bearing offers quiet and efficient operation. Its metric sizing makes it compatible with a wide range of consumer products.
