Single Row Angular Contact Ball Bearings (General) 7214 BEGAP

Single Row Angular Contact Ball Bearings (General) 7214 BEGAP

The 7214 BEGAP is a single-row angular contact ball bearing with a 70mm bore and 125mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 16200 lbf and operates smoothly at speeds up to 6300 RPM.

With a 40° contact angle, it efficiently handles combined radial and axial loads. The open design and nylon cage ensure durability while allowing easy lubrication.

This bearing is interchangeable with SKF models, making it a versatile choice for replacements. Suitable for applications like pumps or gearboxes where angular loads are common.

Weighing 1.1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it works in temperatures from -30°C to 110°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7214 BEGAP
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 125 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 24 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 91.5 mm
  • External Diameter On Inner Ring (Small Side Face) 80.25 mm
  • Internal Diameter On Outer Ring 104.75 mm
  • Chamfer Dimension 1.5 mm
  • Distance Pressure Point (a) 53 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 16200 lbf
  • Static Radial Load 13500 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 1.1 kg
  • Price（$） 55.58
Single Row Angular Contact Ball Bearings (General) 7214 BEGAP dimension drawing
Download DWG Download PDF

Features

Performance Features of 7214 BEGAP Bearing

7214 BEGAP Bearing is designed with a 40° contact angle, optimising load distribution for angular contact applications.
Its chrome steel rings and balls provide strong resistance to both dynamic and static radial loads.

The nylon cage ensures smooth operation and reduces friction, enhancing the bearing’s efficiency.
With a maximum speed of 6,300 rpm, it balances performance and durability in various conditions.

7214 BEGAP Bearing operates effectively within a temperature range of -30° to 110°C.
Its P6 tolerance class guarantees precision and reliability in demanding environments.

Application

Industrial Uses of 7214 BEGAP Bearing
The 7214 BEGAP Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. Its open design and nylon cage make it suitable for high-speed operations in industrial settings.

In automotive applications, 7214 BEGAP Bearing supports components like wheel hubs and transmissions, ensuring smooth performance under angular loads. The metric sizing and P6 tolerance class provide precise fitment for European and Asian vehicles.

For automation systems, 7214 BEGAP Bearing works well in robotic arms and conveyor belts, thanks to its durable chrome steel construction. The lubricated design ensures long service life even in continuous operation.

Where Is 7214 BEGAP Bearing Used?
You’ll often find 7214 BEGAP Bearing in industrial fans and pumps, where its ability to manage angular loads is crucial. The nylon cage reduces friction, making it energy-efficient for prolonged use.

In medical imaging devices, 7214 BEGAP Bearing offers reliable performance due to its precise P6 tolerance. The chrome steel rings and balls ensure minimal wear, even in high-precision applications.

Built for Heavy-Duty Use: 7214 BEGAP Bearing
This bearing excels in construction equipment like excavators, where its robust design handles heavy loads. The 40° contact angle provides stability under demanding conditions.

For household appliances like washing machines, 7214 BEGAP Bearing ensures quiet and smooth operation. Its nylon cage and lubricated design reduce noise and maintenance needs.

Automotive vs Aerospace: Applications of 7214 BEGAP Bearing
In cars, 7214 BEGAP Bearing is ideal for transmissions, offering durability under angular loads. Its P6 tolerance ensures precise alignment for smooth gear shifts.

For aerospace applications, this bearing suits auxiliary systems where reliability is key. The chrome steel construction withstands varying temperatures and stresses.
