Single Row Angular Contact Ball Bearings (General) 7214 BECBY

Single Row Angular Contact Ball Bearings (General) 7214 BECBY

The 7214 BECBY is a single-row angular contact ball bearing with a 70mm bore and 125mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 16200 lbf and operates smoothly at speeds up to 6300 RPM.

Its 40° contact angle efficiently handles combined loads, while the brass cage enhances durability and reduces friction. The open design allows for easy lubrication and maintenance.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Suitable for applications like pumps or gearboxes where angular contact is needed.

Weighing 1.1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s safe for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7214 BECBY
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 125 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 24 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 91.5 mm
  • External Diameter On Inner Ring (Small Side Face) 80.25 mm
  • Internal Diameter On Outer Ring 104.75 mm
  • Chamfer Dimension 1.5 mm
  • Distance Pressure Point (a) 53 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 16200 lbf
  • Static Radial Load 13500 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 1.1 kg
  • Price（$） 55.37
Single Row Angular Contact Ball Bearings (General) 7214 BECBY dimension drawing
Download DWG Download PDF

Features

Performance Features of 7214 BECBY Bearing

7214 BECBY Bearing features a 40° contact angle, optimised for handling combined radial and axial loads.
Its chrome steel construction ensures durability, while the brass cage maintains smooth ball alignment.

With a dynamic radial load capacity of 16,200 lbf, it performs reliably in demanding applications.
The P6 tolerance class (ABEC-3) guarantees precision, suitable for high-speed operations up to 6,300 rpm.

Designed for a temperature range of -30° to 110°C, 7214 BECBY Bearing adapts to various working conditions.
Its open design simplifies lubrication, ensuring consistent performance over time.

Application

Common Applications of 7214 BECBY Bearing
The 7214 BECBY Bearing is widely used in industrial machinery, especially in spindle assemblies and gearboxes where high radial and axial loads are present. Its 40° contact angle provides excellent load distribution, ensuring smooth operation.

In automotive applications, 7214 BECBY Bearing is often found in wheel hubs and transmission systems. The brass cage enhances durability, making it suitable for high-speed rotations and varying load conditions.

For automation equipment, 7214 BECBY Bearing supports robotic arms and precision tools. The P6 tolerance class ensures reliable performance in demanding environments where accuracy is key.

Medical imaging devices also benefit from 7214 BECBY Bearing’s chrome steel construction. Its lubricated design reduces friction, ensuring quiet and efficient operation in sensitive equipment.
