Single Row Angular Contact Ball Bearings (General) 7213 BECBJ

Single Row Angular Contact Ball Bearings (General) 7213 BECBJ

The 7213 BECBJ is a single-row angular contact ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 15638 lbf and operates smoothly at speeds up to 6700 RPM.

With a 40° contact angle, it efficiently handles combined radial and axial loads. The open design allows easy lubrication, while the stainless steel cage ensures durability.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Suitable for machinery like pumps or gearboxes where angular contact is needed.

Weighing 1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it works in temperatures from -30°C to 110°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7213 BECBJ
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 23 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 86.35 mm
  • External Diameter On Inner Ring (Small Side Face) 75.48 mm
  • Internal Diameter On Outer Ring 99.45 mm
  • Chamfer Dimension 1.5 mm
  • Distance Pressure Point (a) 50 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 15638 lbf
  • Static Radial Load 12825 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6700 rpm
  • Weight 1 kg
  • Price（$） 64.02
Single Row Angular Contact Ball Bearings (General) 7213 BECBJ dimension drawing
Download DWG Download PDF

Features

Performance Features of 7213 BECBJ Bearing

7213 BECBJ Bearing is designed with a 40° contact angle, optimising load distribution for angular contact applications.
Its chrome steel rings and balls enhance durability, supporting dynamic radial loads up to 15638 lbf.

The stainless steel cage ensures smooth operation, reducing friction and wear.
With a maximum speed of 6,700 rpm, it balances performance and longevity.

7213 BECBJ Bearing operates efficiently in temperatures from -30° to 110°C.
Its P6 tolerance class ensures precision, making it suitable for demanding industrial uses.

The open seal design simplifies maintenance, while the lubricated construction reduces friction.
Weighing just 1 kg, it offers a practical solution for various mechanical systems.

Application

Industrial Uses of 7213 BECBJ Bearing
The 7213 BECBJ Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. Its open design and stainless steel cage make it suitable for high-speed operations in industrial settings.

In automotive applications, 7213 BECBJ Bearing works well in gearboxes and wheel hubs, providing reliable performance under angular loads. The metric dimensions ensure compatibility with a variety of vehicle designs, from compact cars to light trucks.

For automation systems, 7213 BECBJ Bearing supports robotic arms and conveyor belts, offering smooth motion and durability. The chrome steel construction ensures long service life even in demanding environments.

Medical imaging devices benefit from 7213 BECBJ Bearing’s precision and low friction, ensuring accurate and quiet operation. The P6 tolerance class guarantees consistent performance in sensitive equipment.

In household appliances like washing machines, 7213 BECBJ Bearing provides quiet and efficient operation. Its robust design handles the vibrations and loads typical in daily use.
