Single Row Angular Contact Ball Bearings (General) 7210 BECBY

Single Row Angular Contact Ball Bearings (General) 7210 BECBY

The 7210 BECBY is a single-row angular contact ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 9000 lbf and operates smoothly at speeds up to 9000 RPM.

With a 40° contact angle, it efficiently manages combined radial and axial loads. The brass cage enhances durability and reduces friction during high-speed rotation.

Its open design allows for easy lubrication, while the P6 tolerance class ensures precise performance. Suitable for temperatures from -30°C to 110°C.

Ideal for applications like pumps or gearboxes where angular loads are common. Weighing 0.47kg, it’s a robust yet manageable choice for industrial use. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7210 BECBY
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 20 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 65.75 mm
  • External Diameter On Inner Ring (Small Side Face) 57.68 mm
  • Internal Diameter On Outer Ring 75.15 mm
  • Chamfer Dimension 1.1 mm
  • Distance Pressure Point (a) 39 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 9000 lbf
  • Static Radial Load 6975 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 9000 rpm
  • Weight 0.47 kg
  • Price（$） 32.62
Single Row Angular Contact Ball Bearings (General) 7210 BECBY dimension drawing
Download DWG Download PDF

Features

Why Choose 7210 BECBY Bearing for Precision Tasks?

7210 BECBY Bearing features a 40° contact angle, ideal for handling combined radial and axial loads with precision.
Its chrome steel construction ensures durability, while the brass cage maintains ball alignment for smooth operation.

With a dynamic radial load capacity of 9000 lbf, it performs reliably in demanding applications.
The P6 tolerance class (ABEC-3) guarantees consistent accuracy for high-performance machinery.

Operating at speeds up to 9,000 rpm, it balances efficiency and longevity.
The open design allows easy lubrication, extending maintenance intervals.

Designed for temperatures from -30° to 110°C, it adapts to various working conditions.
Its metric dimensions (50 mm×90 mm×20 mm) ensure compatibility with standard systems.

Application

Industrial Uses of 7210 BECBY Bearing
The 7210 BECBY Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. Its brass cage ensures smooth operation even at high speeds, making it suitable for precision machining.

In automotive applications, 7210 BECBY Bearing supports gearboxes and wheel hubs, providing reliable performance under heavy loads. The chrome steel construction enhances durability, while the open design allows for easy lubrication.

For robotics, 7210 BECBY Bearing is ideal for joint mechanisms, offering stability and precision in repetitive movements. The P6 tolerance class ensures consistent performance in automated systems.

In consumer electronics, 7210 BECBY Bearing can be found in high-performance fans, where its low friction and high-speed capability are key. The metric sizing makes it compatible with various European and Asian designs.

Medical imaging devices benefit from 7210 BECBY Bearing’s smooth operation and reliability. The brass cage reduces wear, ensuring long service life in critical applications.
