Single Row Angular Contact Ball Bearings (General) 70/1060 AMB

Single Row Angular Contact Ball Bearings (General) 70/1060 AMB

The 70/1060 AMB is a large single-row angular contact ball bearing, measuring 1060mm in bore diameter and 1500mm in outer diameter, with a width of 195mm. Made from chrome steel, it’s built to handle heavy radial loads up to 378,000 lbf and operates at speeds up to 340 RPM.

Its 40° contact angle provides stability for angular loads, while the brass cage ensures smooth rotation. The open design allows for easy lubrication, making maintenance straightforward.

This bearing is suitable for heavy-duty applications like industrial machinery or large rotating equipment. It works well in temperatures from -30°C to 110°C and meets P6 tolerance standards.

Weighing 1092kg, it’s a robust choice for demanding environments. Compliant with RoHS and REACH, it’s also interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 70/1060 AMB
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 1060 mm
  • Bore Dia Tolerance -0.075mm to 0
  • Outer Dia 1500 mm
  • Outer Dia Tolerance -0.09mm to 0
  • Width 195 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 1217.6 mm
  • External Diameter On Inner Ring (Small Side Face) 1217.6 mm
  • Internal Diameter On Outer Ring 1343.4 mm
  • Chamfer Dimension 9.5 mm
  • Distance Pressure Point (a) 467 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 378000 lbf
  • Static Radial Load 1282500 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 340 rpm
  • Weight 1092 kg
Single Row Angular Contact Ball Bearings (General) 70/1060 AMB dimension drawing
Download DWG Download PDF

Features

Performance Features of 70/1060 AMB Bearing

70/1060 AMB Bearing is built with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel rings and balls ensure durability, while the brass cage provides smooth operation.

With a dynamic radial load capacity of 378,000 lbf, it performs reliably in heavy-duty applications.
The P6 tolerance class ensures precision, making it suitable for demanding industrial use.

70/1060 AMB Bearing operates within a temperature range of -30° to 110°C, adapting to various environments.
Its open design allows for easy lubrication, reducing maintenance needs over time.

The large bore size of 1060 mm makes it perfect for heavy machinery and industrial equipment.
Despite its size, it maintains a maximum speed of 340 rpm, balancing power and performance.

Application

Industrial Uses of 70/1060 AMB Bearing
The 70/1060 AMB Bearing is commonly used in large industrial machinery, such as heavy-duty presses and rolling mills, where its high load capacity and angular contact design are essential. Its brass cage ensures smooth operation even under significant radial and axial forces.

Where Is 70/1060 AMB Bearing Used?
You’ll often find the 70/1060 AMB Bearing in wind turbine gearboxes, where its ability to handle combined loads makes it a reliable choice. The P6 tolerance class ensures precision in these demanding applications.

Built for Heavy-Duty Use: 70/1060 AMB Bearing
The 70/1060 AMB Bearing excels in mining equipment, supporting massive loads with its chrome steel construction. Its lubricated design helps maintain performance in harsh environments.

Automotive vs Aerospace: Applications of 70/1060 AMB Bearing
In automotive testing rigs, the 70/1060 AMB Bearing handles high loads, while in aerospace, it’s used in ground support equipment. Its 40° contact angle provides stability in both scenarios.

Perfect Fit for Automation: 70/1060 AMB Bearing
The 70/1060 AMB Bearing is ideal for large robotic arms in manufacturing, offering precise movement under heavy loads. Its metric sizing ensures compatibility with European automation systems.
