Self Aligning Ball Bearings KAM 1209

Brand: TFL Bearing Interchangeable: SKF KAM 1209 45 mm × 85 mm × 19 mm Metric Open
Part number: KAM 1209
Self Aligning Ball Bearings KAM 1209
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia45 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia85 mm
Outer Dia Tolerance-0.015mm to 0
Width19 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring57.51 mm
Internal Diameter On Outer Ring72.5 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load5,152 lbf
Static Radial Load1,755 lbf
Temperature Range-30° to 110 °C
Max Speed11,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Radial ClearanceCN
Weight0.47 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialBrass
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The KAM 1209 is a self-aligning ball bearing with a 45mm tapered bore and 85mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 5152 lbf and operates smoothly at speeds reaching 11,000 RPM.

Its double-row design and brass cage provide reliable performance, while the open seal allows for easy lubrication. The bearing functions well in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.47kg, it’s a robust yet manageable size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Features

Why Choose KAM 1209 Bearing for Precision Tasks?

KAM 1209 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 5152 lbf makes it suitable for high-performance applications.

The brass cage maintains ball alignment, reducing friction and enhancing durability.
With a maximum speed of 11,000 rpm, it delivers smooth and efficient operation.

KAM 1209 Bearing operates in temperatures from -30° to 110°C, adapting to various working conditions.
Its tapered bore design simplifies installation, saving time and effort.

The open seal type allows for easy lubrication, ensuring long service life with minimal maintenance.
Its compact size (45 mm×85 mm×19 mm) makes it ideal for space-constrained applications.

Application

Key Fields for KAM 1209 Bearing
KAM 1209 Bearing is commonly used in industrial machinery, especially in conveyor systems and fans, where its self-aligning feature compensates for minor misalignments.
The double-row design ensures reliable performance under radial loads, making it suitable for heavy-duty applications.

In automotive applications, KAM 1209 Bearing can be found in gearboxes and wheel hubs, providing smooth rotation even under varying loads.
Its taper bore design allows for secure fitting, which is essential for high-vibration environments.

For automation equipment, KAM 1209 Bearing supports robotic arms and assembly lines, where precision and durability are key.
The brass cage enhances its longevity, reducing maintenance needs in continuous operation scenarios.

In household appliances like washing machines, KAM 1209 Bearing ensures quiet and efficient performance.
Its chrome steel construction offers resistance to wear, making it a dependable choice for daily use.
