Self Aligning Ball Bearings 2317K

Self Aligning Ball Bearings 2317K

The 2317K is a self-aligning ball bearing with an 85mm tapered bore and 180mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 31500 lbf and runs smoothly at speeds up to 4800 RPM.

Its double-row design and open seal allow for easy lubrication, while the nylon cage reduces noise and wear. The bearing operates well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Perfect for machinery with misalignment issues, like conveyor systems or agricultural equipment.

Weighing 6.8kg, it’s a robust choice for heavy-duty applications. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2317K
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 60 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 115 mm
  • Internal Diameter On Outer Ring 153.5 mm
  • Chamfer Dimension 3 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 31500 lbf
  • Static Radial Load 11475 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 6.8 kg
Self Aligning Ball Bearings 2317K dimension drawing
Download DWG Download PDF

Features

Why Choose 2317K Bearing for Precision Tasks?

2317K Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity up to 31,500 lbf.
The tapered bore design allows for precise alignment, reducing stress and wear during operation.

With a nylon cage, 2317K Bearing maintains smooth rotation while minimising noise and vibration.
Its maximum speed of 4,800 rpm makes it suitable for various industrial applications.

The radial clearance classification CN ensures consistent performance under different operating conditions.
2317K Bearing operates reliably in temperatures ranging from -30° to 110°C.

Application

Industrial Uses of 2317K Bearing
2317K Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable radial load handling in demanding environments.

Where Is 2317K Bearing Used?
You’ll often find 2317K Bearing in automotive applications, such as truck wheel hubs, where its taper bore provides a secure fit. The nylon cage reduces friction, making it suitable for high-speed rotations.

Built for Heavy-Duty Use: 2317K Bearing
2317K Bearing excels in construction equipment, where its chrome steel construction withstands heavy radial loads. The open seal design allows for easy lubrication, extending its service life.

Automotive vs Aerospace: Applications of 2317K Bearing
In automotive settings, 2317K Bearing handles wheel loads, while in aerospace, it supports auxiliary systems. Its metric sizing ensures compatibility with a range of international machinery.

Perfect Fit for Automation: 2317K Bearing
2317K Bearing is ideal for robotic arms in automated production lines, thanks to its self-aligning capability. The lubricated design ensures smooth operation even during continuous use.
