Self Aligning Ball Bearings 2310KJC3

Brand: TFL Bearing Interchangeable: SKF 2310KJC3 50 mm × 110 mm × 40 mm Metric Open
Part number: 2310KJC3
Self Aligning Ball Bearings 2310KJC3
In Stock
US$89.49 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia50 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia110 mm
Outer Dia Tolerance-0.015mm to 0
Width40 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring66 mm
Internal Diameter On Outer Ring92.5 mm
Chamfer Dimension2 mm
Performance
Dynamic Radial Load14,332 lbf
Static Radial Load4,500 lbf
Temperature Range-30° to 110 °C
Max Speed8,500 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Radial ClearanceC3
Weight1.65 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialSteel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2310KJC3 is a self-aligning ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 14332 lbf and operates smoothly at speeds up to 8500 RPM.

Its double-row design and open seal allow for easy lubrication and adaptability to slight misalignments. The steel cage enhances durability, making it suitable for demanding environments.

This bearing works well in temperatures ranging from -30°C to 110°C and is interchangeable with SKF models. Ideal for machinery like conveyors or fans where alignment flexibility is needed.

Weighing 1.65kg, it offers a robust yet manageable solution for industrial applications. Compliant with RoHS and REACH standards for safety and environmental care.

Features

Why Choose 2310KJC3 Bearing for Precision Tasks?

2310KJC3 Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load reaches 14332 lbf, making it suitable for demanding applications.

The tapered bore design of 2310KJC3 Bearing allows for secure mounting and precise alignment.
This reduces vibration and enhances operational stability.

With a maximum speed of 8,500 rpm, 2310KJC3 Bearing balances performance and durability.
The C3 radial clearance ensures smooth operation under varying thermal conditions.

2310KJC3 Bearing’s steel cage maintains ball alignment, extending service life.
Its open design simplifies lubrication, reducing maintenance needs.

Application

Industrial Uses of 2310KJC3 Bearing
2310KJC3 Bearing is commonly used in industrial machinery like conveyor systems and mixers, where its self-aligning feature compensates for minor misalignments. The double-row design provides added stability under radial loads, making it suitable for heavy-duty applications.

In automotive applications, 2310KJC3 Bearing can be found in gearboxes and drivetrains, where its tapered bore ensures a secure fit. The chrome steel construction offers durability, even under constant vibration and high-speed conditions.

For automation equipment, 2310KJC3 Bearing supports robotic arms and assembly lines, thanks to its smooth operation and C3 radial clearance. The open seal design allows for easy lubrication, extending its service life in demanding environments.

Where Is 2310KJC3 Bearing Used?
You’ll often spot 2310KJC3 Bearing in industrial fans and blowers, where its self-aligning capability reduces wear from shaft deflection. The steel cage adds robustness, ensuring reliable performance over time.

In construction machinery, 2310KJC3 Bearing handles radial loads in equipment like cement mixers and cranes. Its metric sizing and tapered bore make it a versatile choice for various European and Asian machinery standards.

Built for Heavy-Duty Use: 2310KJC3 Bearing
2310KJC3 Bearing excels in mining equipment, where its double-row design withstands harsh conditions. The C3 clearance accommodates thermal expansion, preventing premature failure.

For agricultural machinery, 2310KJC3 Bearing is ideal for tractors and harvesters, thanks to its ability to handle misalignment. The lubricated design ensures smooth operation, even in dusty environments.

Light-Duty vs Heavy-Duty: Best Uses for 2310KJC3 Bearing
In light-duty applications like small pumps, 2310KJC3 Bearing offers quiet and efficient performance. The chrome steel balls reduce friction, enhancing energy efficiency.

For heavy-duty scenarios like industrial compressors, 2310KJC3 Bearing’s dynamic load capacity ensures longevity. Its open seal allows for easy maintenance, reducing downtime in critical operations.
