Self Aligning Ball Bearings 2310 M C/3

Brand: TFL Bearing Interchangeable: SKF 2310 M C/3 50 mm × 110 mm × 40 mm Metric Open
Part number: 2310 M C/3
Self Aligning Ball Bearings 2310 M C/3
In Stock
US$165.91 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia50 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia110 mm
Outer Dia Tolerance-0.015mm to 0
Width40 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring66 mm
Internal Diameter On Outer Ring92.5 mm
Chamfer Dimension2 mm
Performance
Dynamic Radial Load14,332 lbf
Static Radial Load4,500 lbf
Temperature Range-30° to 110 °C
Max Speed8,500 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeCylindrical
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Radial ClearanceCN
Weight1.86 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialBrass
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2310 M C/3 is a self-aligning ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 14332 lbf and operates smoothly at speeds up to 8500 RPM.

Its double-row design and open construction allow for easy lubrication and alignment adjustments. The brass cage enhances durability and reduces friction during use.

This bearing works well in temperatures from -30°C to 110°C, making it suitable for various environments. It’s interchangeable with SKF bearings, offering a reliable replacement option.

Weighing 1.86kg, it’s a robust choice for industrial machinery or equipment requiring radial load support. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Features

Performance Features of 2310 M C/3 Bearing

2310 M C/3 Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 14332 lbf, ensuring reliable performance in various applications.
The brass cage maintains ball alignment, reducing friction and extending operational life.
With a maximum speed of 8,500 rpm, it delivers a balance of durability and efficiency.

How Does 2310 M C/3 Bearing Reduce Friction?

2310 M C/3 Bearing features a double-row design that distributes loads evenly, minimising friction during operation.
The brass cage ensures smooth movement of the balls, contributing to quieter performance.
Its chrome steel construction enhances durability while maintaining low friction levels.
This makes it suitable for applications where smooth rotation is essential.

Engineered for Precision: 2310 M C/3 Bearing

2310 M C/3 Bearing’s cylindrical bore design ensures precise fitting and alignment on shafts.
The double-row construction provides stability, even under heavy radial loads.
With a radial clearance of CN, it offers optimal performance for various industrial uses.
Its temperature range of -30° to 110 °C ensures reliability in different working conditions.

Why Choose 2310 M C/3 Bearing for Precision Tasks?

2310 M C/3 Bearing’s chrome steel components provide consistent performance in precision applications.
The open seal design allows for easy lubrication, maintaining smooth operation over time.
Its 50 mm bore diameter and 110 mm outer diameter offer a robust solution for radial load requirements.
The bearing’s brass cage adds to its precision by ensuring proper ball alignment.

Application

Industrial Uses of 2310 M C/3 Bearing
2310 M C/3 Bearing is commonly used in industrial machinery like conveyor belts and mixers, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable performance under heavy radial loads.

Where Is 2310 M C/3 Bearing Used?
In automotive applications, 2310 M C/3 Bearing fits well in gearboxes and drivetrains, handling radial forces efficiently. Its brass cage reduces friction, making it suitable for high-speed operations.

Built for Heavy-Duty Use: 2310 M C/3 Bearing
For construction equipment, 2310 M C/3 Bearing provides durability in cranes and excavators. The chrome steel construction ensures long-lasting performance even in tough conditions.

Automotive vs Aerospace: Applications of 2310 M C/3 Bearing
In automotive systems, 2310 M C/3 Bearing supports drivetrains, while in aerospace, it aids in auxiliary equipment. Its metric sizing makes it versatile for various industries.

Perfect Fit for Automation: 2310 M C/3 Bearing
2310 M C/3 Bearing works well in robotic arms and automated assembly lines. The self-aligning capability ensures smooth operation even with slight shaft misalignments.
