Self Aligning Ball Bearings 2310 M C/2

Self Aligning Ball Bearings 2310 M C/2

The 2310 M C/2 is a self-aligning ball bearing with a 50mm bore and 110mm outer diameter, designed for radial loads. Made from chrome steel with a brass cage, it offers durability and smooth operation.

It handles dynamic radial loads up to 14332 lbf and can spin at speeds up to 8500 RPM. The double-row design helps it manage misalignment, making it reliable in demanding conditions.

Its open construction allows for easy lubrication, and it performs well in temperatures from -30°C to 110°C. The bearing is interchangeable with SKF models, simplifying replacements.

Ideal for industrial machinery or heavy equipment where alignment issues might occur. Weighing 1.86kg, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2310 M C/2
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 40 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 66 mm
  • Internal Diameter On Outer Ring 92.5 mm
  • Chamfer Dimension 2 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 14332 lbf
  • Static Radial Load 4500 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 8500 rpm
  • Weight 1.86 kg
  • Price（$） 199.18
Self Aligning Ball Bearings 2310 M C/2 dimension drawing
Download DWG Download PDF

Features

What Makes 2310 M C/2 Bearing Suitable for High-Temperature Applications?

2310 M C/2 Bearing is crafted from chrome steel rings and balls, ensuring durability in temperatures ranging from -30° to 110°C.
Its brass cage maintains alignment under high-speed conditions, reducing friction and wear.
The double-row design enhances load distribution, supporting dynamic radial loads up to 14332 lbf.
With a maximum speed of 8,500 rpm, it delivers reliable performance in demanding environments.

Application

Common Applications of 2310 M C/2 Bearing
2310 M C/2 Bearing is widely used in industrial machinery, especially in applications where misalignment compensation is needed, such as conveyor systems and fans. Its double-row design helps distribute loads evenly, ensuring smooth operation.

In automotive applications, 2310 M C/2 Bearing can be found in gearboxes and drivetrains, where its radial load capacity and self-aligning feature reduce wear. The brass cage adds durability, making it suitable for high-vibration environments.

For automation equipment, 2310 M C/2 Bearing supports robotic arms and assembly lines, where precision and reliability are key. The open seal design allows for easy lubrication, extending its service life in continuous operations.

In household appliances like washing machines, 2310 M C/2 Bearing provides quiet and efficient performance. Its chrome steel construction ensures long-term reliability even under frequent use.
