Self Aligning Ball Bearings 2310 KM/C3

Self Aligning Ball Bearings 2310 KM/C3

The 2310 KM/C3 is a self-aligning ball bearing with a 50mm bore and 110mm outer diameter, built from sturdy chrome steel. It manages radial loads up to 14332 lbf and runs smoothly at speeds up to 8500 RPM.

Its double-row design and brass cage offer durability, while the open seal allows easy lubrication. The bearing operates well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for machinery with misalignment issues, like conveyor systems or agricultural equipment.

Weighing 1.55kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2310 KM/C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 40 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 66 mm
  • Internal Diameter On Outer Ring 92.5 mm
  • Chamfer Dimension 2 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 14332 lbf
  • Static Radial Load 4500 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 8500 rpm
  • Weight 1.55 kg
Self Aligning Ball Bearings 2310 KM/C3 dimension drawing
Download DWG Download PDF

Features

How Does 2310 KM/C3 Bearing Reduce Friction?

2310 KM/C3 Bearing features a double-row ball design with chrome steel rings and balls, ensuring smooth radial load distribution.
The brass cage maintains proper ball alignment, minimising friction and wear during operation.
With a dynamic radial load capacity of 14332 lbf, it handles demanding applications efficiently.
Its C3 radial clearance allows for thermal expansion, enhancing performance in varying temperatures.

Application

Industrial Uses of 2310 KM/C3 Bearing
2310 KM/C3 Bearing is commonly used in heavy machinery, such as conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable performance under radial loads, making it suitable for demanding environments.

In automotive applications, 2310 KM/C3 Bearing supports components like drive shafts and wheel hubs, providing smooth rotation even under varying loads. Its brass cage enhances durability, making it a dependable choice for long-term use.

For automation equipment, 2310 KM/C3 Bearing’s tapered bore allows for easy installation in robotic arms and assembly lines. The C3 radial clearance ensures optimal performance in high-speed operations, reducing friction and wear.

Medical devices benefit from 2310 KM/C3 Bearing’s precision, particularly in imaging equipment where consistent movement is essential. The chrome steel construction ensures longevity, even in high-use scenarios.
