Self Aligning Ball Bearings 2307 EKM

Brand: TFL Bearing Interchangeable: SKF 2307 EKM 35 mm × 80 mm × 31 mm Metric Open
Part number: 2307 EKM
Self Aligning Ball Bearings 2307 EKM
In Stock
US$40.68 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia35 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia80 mm
Outer Dia Tolerance-0.013mm to 0
Width31 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring46.7 mm
Internal Diameter On Outer Ring67 mm
Chamfer Dimension1.5 mm
Performance
Dynamic Radial Load8,932 lbf
Static Radial Load2,520 lbf
Temperature Range-30° to 110 °C
Max Speed12,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Weight0.75 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2307 EKM is a self-aligning ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 8932 lbf and operates smoothly at speeds up to 12000 RPM.

Its double-row design and open construction allow for easy lubrication and alignment adjustments. The nylon cage reduces friction, enhancing durability and performance.

This bearing is interchangeable with SKF models, making it a versatile choice for replacements. It’s well-suited for applications like conveyor systems or agricultural machinery where misalignment can occur.

Weighing 0.75kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s safe for use in temperatures ranging from -30°C to 110°C.

Features

How Does 2307 EKM Bearing Reduce Friction?

2307 EKM Bearing features a double-row ball design, ensuring smooth radial load distribution and reduced friction.
Its chrome steel construction enhances durability while maintaining efficient operation under high speeds.
The nylon cage minimises contact friction, contributing to quieter performance and longer service life.
With a maximum speed of 12,000 rpm, it is ideal for applications requiring both speed and reliability.

Application

Industrial Uses of 2307 EKM Bearing
2307 EKM Bearing is commonly used in industrial fans and blowers, where its self-aligning feature compensates for minor misalignments. The double-row design ensures stable performance even under heavy radial loads.

In conveyor systems, 2307 EKM Bearing reduces downtime by handling misalignment and high-speed rotations smoothly. Its nylon cage offers quiet operation, ideal for noise-sensitive environments.

For agricultural machinery, 2307 EKM Bearing’s robust construction withstands harsh conditions like dust and moisture. The chrome steel rings provide long-lasting durability in demanding applications.

Where Is 2307 EKM Bearing Used?
You’ll find 2307 EKM Bearing in electric motors, where its ability to handle radial loads and misalignment improves efficiency. The lubricated design ensures consistent performance over time.

In food processing equipment, 2307 EKM Bearing’s open design allows for easy cleaning and maintenance. The metric sizing makes it a versatile choice for various European machinery standards.

Built for Heavy-Duty Use: 2307 EKM Bearing
2307 EKM Bearing excels in construction equipment, where its high dynamic radial load capacity is essential. The chrome steel balls and rings offer reliable performance under stress.

In printing machinery, 2307 EKM Bearing’s self-aligning capability ensures precise paper handling. The nylon cage reduces friction, extending the bearing’s lifespan.

Automotive vs Aerospace: Applications of 2307 EKM Bearing
In automotive applications, 2307 EKM Bearing supports components like pumps and compressors, where misalignment tolerance is key. Its metric dimensions fit seamlessly into European vehicle designs.

For aerospace ground equipment, 2307 EKM Bearing’s lightweight yet durable construction is ideal. The temperature range suits both indoor and outdoor operational environments.
