Self Aligning Ball Bearings 2307-2RSTN

Self Aligning Ball Bearings 2307-2RSTN

The 2307-2RSTN is a self-aligning ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 5962 lbf and operates smoothly at speeds up to 5600 RPM.
Its sealed design keeps lubrication in and contaminants out, while the nylon cage reduces friction for quieter performance. The bearing works reliably in temperatures from -30°C to 110°C.
This double-row construction helps compensate for minor misalignments, making it a practical choice for applications like conveyor systems or agricultural machinery.
Weighing 0.7kg, it’s a durable yet lightweight solution for radial load challenges, compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2307-2RSTN
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 31 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 43.7 mm
  • Internal Diameter On Outer Ring 69.2 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5962 lbf
  • Static Radial Load 1912 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 0.7 kg
  • Price（$） 104.58
Self Aligning Ball Bearings 2307-2RSTN dimension drawing
Download DWG Download PDF

Features

How Does 2307-2RSTN Bearing Ensure Smooth Radial Load Handling?

2307-2RSTN Bearing features a double-row ball design, providing excellent radial load capacity up to 5962 lbf.
Its chrome steel construction ensures durability and resistance to wear in various applications.

The sealed design of 2307-2RSTN Bearing keeps contaminants out, maintaining smooth operation.
With a maximum speed of 5,600 rpm, it offers reliable performance in demanding conditions.

2307-2RSTN Bearing’s nylon cage reduces friction and noise, enhancing operational efficiency.
Its wide temperature range of -30° to 110°C makes it suitable for diverse environments.

The pre-lubricated design of 2307-2RSTN Bearing minimises maintenance needs, saving time and costs.
Its precise tolerances ensure consistent performance and easy integration into existing systems.

Application

Industrial Uses of 2307-2RSTN Bearing
2307-2RSTN Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design helps keep contaminants out, extending the bearing’s lifespan in dusty environments.

In automotive applications, 2307-2RSTN Bearing works well in wheel hubs and transmissions, handling radial loads efficiently. Its nylon cage reduces noise, making it suitable for passenger vehicles.

For automation equipment, 2307-2RSTN Bearing ensures smooth operation in robotic arms and assembly lines. The double-row construction provides added stability under varying load conditions.

In household appliances like washing machines, 2307-2RSTN Bearing offers reliable performance with minimal maintenance. The lubricated design ensures quiet operation, even during prolonged use.
