Self Aligning Ball Bearings 2306E-2RS C/2

Brand: TFL Bearing Interchangeable: SKF 2306E-2RS C/2 30 mm × 72 mm × 27 mm Metric Sealed
Part number: 2306E-2RS C/2
Self Aligning Ball Bearings 2306E-2RS C/2
In Stock
US$74.12 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia30 mm
Bore Dia Tolerance-0.01mm to 0
Outer Dia72 mm
Outer Dia Tolerance-0.013mm to 0
Width27 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring40.4 mm
Internal Diameter On Outer Ring61.88 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load5,062 lbf
Static Radial Load1,530 lbf
Temperature Range-30° to 110 °C
Max Speed6,700 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeCylindrical
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.51 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2306E-2RS C/2 is a self-aligning ball bearing with a 30mm bore and 72mm outer diameter, designed for radial loads. Made from chrome steel, it handles dynamic loads up to 5062 lbf and operates smoothly at speeds up to 6700 RPM.

Its double-row construction and sealed design provide reliable performance, while the nylon cage reduces friction. The bearing works in temperatures from -30°C to 110°C and comes pre-lubricated for easy use.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.51kg, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Features

Why Choose 2306E-2RS C/2 Bearing for Precision Tasks?

2306E-2RS C/2 Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load rating of 5062 lbf makes it suitable for demanding applications requiring precision.

The sealed construction of 2306E-2RS C/2 Bearing protects against dust and moisture, enhancing durability.
With a maximum speed of 6,700 rpm, it delivers smooth and reliable performance.

The nylon cage in 2306E-2RS C/2 Bearing reduces friction and noise, ideal for quiet operation.
Its temperature range of -30° to 110°C ensures adaptability in various environments.

Application

Industrial Uses of 2306E-2RS C/2 Bearing
2306E-2RS C/2 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, extending service life in dusty environments.

In automotive applications, 2306E-2RS C/2 Bearing fits well in wheel hubs and transmissions, thanks to its radial load capacity. The nylon cage reduces noise, making it suitable for passenger vehicles.

For robotics, 2306E-2RS C/2 Bearing ensures smooth movement in joints and pivots. Its double-row construction provides stability, while the chrome steel balls offer consistent performance.

In household appliances like washing machines, 2306E-2RS C/2 Bearing handles unbalanced loads with ease. The lubricated design ensures quiet operation, even during high-speed spins.
