Self Aligning Ball Bearings 2306-TVH-C3

Self Aligning Ball Bearings 2306-TVH-C3

The 2306-TVH-C3 is a self-aligning ball bearing with a 30mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 7020 lbf and operates smoothly at speeds reaching 13,000 RPM.

Its double-row design and open seal allow for slight misalignment adjustments, while the nylon cage reduces friction. The bearing is pre-lubricated and works in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a reliable alternative for replacements. Suitable for machinery where alignment flexibility is needed, like conveyor systems or agricultural equipment.

Weighing 0.5kg, it’s a robust yet manageable size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2306-TVH-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 27 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 41.9 mm
  • Internal Diameter On Outer Ring 59.8 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 7020 lbf
  • Static Radial Load 1980 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 0.5 kg
  • Price（$） 45.94
Self Aligning Ball Bearings 2306-TVH-C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 2306-TVH-C3 Bearing

2306-TVH-C3 Bearing is built with chrome steel rings and balls, offering strong radial load capacity.
Its double-row design ensures stability and smooth operation under dynamic loads up to 7020 lbf.

The nylon cage in 2306-TVH-C3 Bearing reduces friction and noise, enhancing performance.
With a maximum speed of 13,000 rpm, it suits high-speed applications while maintaining durability.

2306-TVH-C3 Bearing operates efficiently in temperatures from -30° to 110°C, adapting to various environments.
Its C3 radial clearance provides flexibility, ensuring reliable performance under different conditions.

The open seal design of 2306-TVH-C3 Bearing simplifies maintenance and reduces operational costs.
Its cylindrical bore ensures easy installation, saving time and effort during setup.

Application

Industrial Uses of 2306-TVH-C3 Bearing
2306-TVH-C3 Bearing is commonly used in industrial fans and blowers, where its self-aligning feature compensates for minor misalignments. The double-row design provides reliable radial load support, ensuring smooth operation in demanding environments.

Where Is 2306-TVH-C3 Bearing Used?
In conveyor systems, 2306-TVH-C3 Bearing handles radial loads efficiently, thanks to its chrome steel construction. The open seal type allows for easy lubrication, extending service life in high-speed applications.

Built for Heavy-Duty Use: 2306-TVH-C3 Bearing
2306-TVH-C3 Bearing excels in agricultural machinery, such as grain augers, where dust and debris are common. Its nylon cage reduces friction, making it a durable choice for rough conditions.

Automotive vs Aerospace: Applications of 2306-TVH-C3 Bearing
In automotive wheel hubs, 2306-TVH-C3 Bearing offers stability under radial loads, while its metric sizing ensures compatibility. For aerospace applications, its temperature range suits auxiliary equipment like hydraulic pumps.

Perfect Fit for Automation: 2306-TVH-C3 Bearing
2306-TVH-C3 Bearing is ideal for robotic arms, where precision and flexibility are key. The C3 radial clearance accommodates thermal expansion, maintaining performance in automated assembly lines.
