Self Aligning Ball Bearings 2306 M

Self Aligning Ball Bearings 2306 M

The 2306 M is a self-aligning ball bearing with a 30mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 7020 lbf and operates smoothly at speeds reaching 13,000 RPM.

Its double-row design and open seal type allow for easy lubrication and maintenance, while the nylon cage reduces friction for quieter performance. The bearing functions reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.56kg, it’s a robust yet manageable choice for industrial settings. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2306 M
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 27 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 41.9 mm
  • Internal Diameter On Outer Ring 59.8 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 7020 lbf
  • Static Radial Load 1980 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 0.56 kg
  • Price（$） 70.52
Self Aligning Ball Bearings 2306 M dimension drawing
Download DWG Download PDF

Features

How Does 2306 M Bearing Reduce Friction?

2306 M Bearing features chrome steel rings and balls, designed to minimise friction during operation.
Its double-row construction ensures even load distribution, enhancing smooth performance under radial loads.
The nylon cage helps maintain ball alignment, reducing wear and improving efficiency.
With a maximum speed of 13,000 rpm, it offers reliable performance in various applications.

Application

Industrial Uses of 2306 M Bearing
2306 M Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The double-row design provides reliable radial load support in continuous operation environments.

Where Is 2306 M Bearing Used?
In automotive applications, 2306 M Bearing fits well in wheel hubs and transmissions, thanks to its durable chrome steel construction. The nylon cage reduces friction, enhancing performance in high-speed scenarios.

Built for Heavy-Duty Use: 2306 M Bearing
For industrial fans and blowers, 2306 M Bearing offers smooth rotation with its open design and lubricated setup. Its metric sizing ensures compatibility with a variety of machinery across different regions.

Automotive vs Industrial: Applications of 2306 M Bearing
In robotics, 2306 M Bearing supports joint movements, where its self-aligning capability is crucial for precision. The wide temperature range also makes it suitable for diverse operating conditions.

Key Fields for 2306 M Bearing
2306 M Bearing is a solid choice for printing machinery, where consistent radial load handling is needed. The chrome steel rings and balls ensure long service life even under frequent use.
