Self Aligning Ball Bearings 2304 M

Self Aligning Ball Bearings 2304 M

The 2304 M is a self-aligning ball bearing with a 20mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4095 lbf and operates smoothly at speeds up to 19,000 RPM.

Its double-row design and open seal allow for easy alignment and maintenance, while the nylon cage reduces friction. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.23kg, it’s a lightweight yet durable choice. Compliant with RoHS and REACH standards, it’s safe for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2304 M
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 21 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 29.15 mm
  • Internal Diameter On Outer Ring 41.9 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4095 lbf
  • Static Radial Load 1069 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 19000 rpm
  • Weight 0.23 kg
  • Price（$） 21.77
Self Aligning Ball Bearings 2304 M dimension drawing
Download DWG Download PDF

Features

How Does 2304 M Bearing Reduce Friction?

2304 M Bearing features chrome steel rings and balls, designed to minimise friction during operation.
Its double-row construction ensures even load distribution, enhancing smooth performance.
The nylon cage helps reduce noise and vibration, making it suitable for precision applications.
With a maximum speed of 19,000 rpm, it offers both efficiency and durability.

Why Choose 2304 M Bearing for Precision Tasks?

2304 M Bearing’s chrome steel components provide reliable performance under radial loads.
The double-row design allows for better alignment, reducing wear over time.
Its nylon cage contributes to quieter operation, ideal for sensitive equipment.
With a dynamic radial load capacity of 4095 lbf, it handles demanding tasks with ease.

Engineered for Precision: 2304 M Bearing

2304 M Bearing is built with high-quality chrome steel for consistent performance.
The double-row construction ensures stability, even under varying load conditions.
Its lubricated design reduces maintenance needs while extending service life.
Operating within a temperature range of -30° to 110°C, it adapts to diverse environments.

Application

Industrial Uses of 2304 M Bearing
2304 M Bearing is commonly used in industrial fans and blowers, where its self-aligning feature compensates for minor misalignments. The double-row design ensures stable performance even under varying radial loads.

Where Is 2304 M Bearing Used?
In conveyor systems, 2304 M Bearing handles misalignment and radial loads efficiently, reducing maintenance needs. Its nylon cage offers quiet operation, ideal for noise-sensitive environments.

Built for Heavy-Duty Use: 2304 M Bearing
2304 M Bearing excels in agricultural machinery, such as grain augers, thanks to its robust chrome steel construction. The lubricated design extends service life in dusty conditions.

Automotive vs Aerospace: Applications of 2304 M Bearing
In automotive steering columns, 2304 M Bearing provides smooth rotation and durability. For aerospace applications, its lightweight design and reliability make it suitable for auxiliary systems.

Perfect Fit for Automation: 2304 M Bearing
2304 M Bearing is a reliable choice for robotic arms, where precision and flexibility are key. The open seal type allows for easy re-lubrication in high-use automation setups.
