Self Aligning Ball Bearings 2205 K 2RS C3

Brand: TFL Bearing Interchangeable: SKF 2205 K 2RS C3 25 mm × 52 mm × 18 mm Metric Sealed
Part number: 2205 K 2RS C3
Self Aligning Ball Bearings 2205 K 2RS C3
In Stock
US$34.78 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia25 mm
Bore Dia Tolerance-0.01mm to 0
Outer Dia52 mm
Outer Dia Tolerance-0.013mm to 0
Width18 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring31 mm
Internal Diameter On Outer Ring46.21 mm
Chamfer Dimension1 mm
Performance
Dynamic Radial Load3,218 lbf
Static Radial Load900 lbf
Temperature Range-30° to 110 °C
Max Speed9,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceC3
Weight0.16 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2205 K 2RS C3 is a self-aligning ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3218 lbf and operates smoothly at speeds up to 9000 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, while the nylon cage reduces friction. The bearing comes pre-lubricated and works in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Perfect for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing just 0.16kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Features

Why Choose 2205 K 2RS C3 Bearing for Precision Tasks?

2205 K 2RS C3 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 3218 lbf makes it suitable for high-performance applications.
The sealed construction and nylon cage provide protection against contaminants while reducing friction.
With a maximum speed of 9,000 rpm, it offers both durability and smooth operation.

Application

Industrial Uses of 2205 K 2RS C3 Bearing
2205 K 2RS C3 Bearing is commonly used in industrial machinery, especially in conveyor systems and pumps, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring longer service life in dusty environments.

In automotive applications, 2205 K 2RS C3 Bearing fits well in wheel hubs and transmissions, thanks to its radial load capacity and tapered bore. The nylon cage reduces noise, making it suitable for passenger vehicles.

For medical devices like diagnostic equipment, 2205 K 2RS C3 Bearing offers reliable performance with its chrome steel construction. The lubricated design ensures smooth operation, which is critical for precision instruments.

In home appliances such as washing machines, 2205 K 2RS C3 Bearing handles radial loads effectively while maintaining quiet operation. Its sealed design also protects against moisture and detergent ingress.

Automation systems benefit from 2205 K 2RS C3 Bearing’s ability to handle misalignment in robotic arms. The C3 radial clearance provides flexibility in high-speed applications.
