Self Aligning Ball Bearings 2205 2RS C3

Brand: TFL Bearing Interchangeable: SKF 2205 2RS C3 25 mm × 52 mm × 18 mm Metric Sealed
Part number: 2205 2RS C3
Self Aligning Ball Bearings 2205 2RS C3
In Stock
US$34.78 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia25 mm
Bore Dia Tolerance-0.01mm to 0
Outer Dia52 mm
Outer Dia Tolerance-0.013mm to 0
Width18 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring31 mm
Internal Diameter On Outer Ring46.21 mm
Chamfer Dimension1 mm
Performance
Dynamic Radial Load3,218 lbf
Static Radial Load900 lbf
Temperature Range-30° to 110 °C
Max Speed9,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeCylindrical
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceC3
Weight0.16 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2205 2RS C3 is a self-aligning ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3218 lbf and operates smoothly at speeds up to 9000 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, while the nylon cage reduces friction. The bearing works reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing just 0.16kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Features

How Is 2205 2RS C3 Bearing Engineered for Reliability?

2205 2RS C3 Bearing features a double-row design with chrome steel rings and balls, ensuring strong radial load capacity.
Its dynamic radial load reaches 3218 lbf, making it suitable for various industrial applications.

The sealed construction of 2205 2RS C3 Bearing protects against contaminants, enhancing durability.
With a maximum speed of 9,000 rpm, it delivers consistent performance under demanding conditions.

2205 2RS C3 Bearing’s nylon cage reduces friction and noise, improving operational efficiency.
Its C3 radial clearance allows for thermal expansion, ensuring reliable performance in varying temperatures.

Application

Common Applications of 2205 2RS C3 Bearing
In industrial settings, 2205 2RS C3 Bearing is a go-to for conveyor systems and pumps, thanks to its self-aligning feature that compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life even in dusty environments.

Where Is 2205 2RS C3 Bearing Used?
You’ll often spot 2205 2RS C3 Bearing in automotive applications like electric motors and gearboxes, where its radial load capacity and smooth operation are key. The nylon cage reduces friction, making it quieter and more efficient.

Built for Heavy-Duty Use: 2205 2RS C3 Bearing
For robotics and automation, 2205 2RS C3 Bearing offers reliable performance in robotic arms and assembly lines. Its C3 radial clearance allows for thermal expansion, ideal for high-speed operations.

Automotive vs Industrial: Applications of 2205 2RS C3 Bearing
In automotive systems, 2205 2RS C3 Bearing handles radial loads in wheel hubs and transmissions, while in industrial gearboxes, it ensures smooth rotation under varying loads. The chrome steel construction adds durability in both scenarios.

Practical Applications of 2205 2RS C3 Bearing
Household appliances like washing machines benefit from 2205 2RS C3 Bearing’s sealed design, which prevents grease leakage and reduces maintenance. Its compact size fits neatly into tight spaces without compromising performance.
