Self Aligning Ball Bearings 2213 E-2RS1TN9/C3

Self Aligning Ball Bearings 2213 E-2RS1TN9/C3

The 2213 E-2RS1TN9/C3 is a self-aligning ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 7898 lbf and operates smoothly at speeds up to 3600 RPM.

Its double-row design and sealed construction keep dirt out while the nylon cage reduces friction for quieter performance. The bearing comes pre-lubricated and works in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for machinery with misalignment issues, such as conveyor systems or agricultural equipment.

Weighing 1.4kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2213 E-2RS1TN9/C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 31 mm
  • Width Tolerance -0.15mm to 0
  • External Diameter On Inner Ring 79.3 mm
  • Internal Diameter On Outer Ring 105.8 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 7898 lbf
  • Static Radial Load 3150 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3600 rpm
  • Weight 1.4 kg
Self Aligning Ball Bearings 2213 E-2RS1TN9/C3 dimension drawing
Download DWG Download PDF

Features

How Does 2213 E-2RS1TN9/C3 Bearing Ensure Smooth Radial Load Handling?

2213 E-2RS1TN9/C3 Bearing features a double-row design with chrome steel rings and balls, providing excellent radial load capacity.

Its dynamic radial load rating of 7898 lbf ensures reliable performance in various applications.

The sealed design and nylon cage help maintain lubrication and reduce wear, extending the bearing’s service life.

With a maximum speed of 3,600 rpm, it offers a balance of durability and efficiency.

Application

Industrial Uses of 2213 E-2RS1TN9/C3 Bearing
2213 E-2RS1TN9/C3 Bearing is commonly used in conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life in dusty environments.

In automotive applications, 2213 E-2RS1TN9/C3 Bearing fits well in wheel hubs and transmissions, handling radial loads with ease. Its nylon cage reduces noise, making it suitable for passenger vehicles.

For automation equipment, 2213 E-2RS1TN9/C3 Bearing’s double-row construction provides stability in robotic arms and assembly lines. The C3 clearance allows for thermal expansion, maintaining performance under varying temperatures.

In household appliances like washing machines, 2213 E-2RS1TN9/C3 Bearing offers reliable operation with minimal maintenance. The lubricated design ensures smooth rotation, even under constant use.
