Self Aligning Ball Bearings 2210-K-2RS-TVH-C3

Self Aligning Ball Bearings 2210-K-2RS-TVH-C3

The 2210-K-2RS-TVH-C3 is a self-aligning ball bearing with a 50mm tapered bore and 90mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 5152 lbf and runs smoothly at speeds up to 4800 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, while the nylon cage reduces friction. The bearing comes pre-lubricated and works in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a reliable alternative. Perfect for machinery with misalignment issues, like conveyor systems or agricultural equipment.

Weighing 0.57kg, it’s a robust yet manageable size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2210-K-2RS-TVH-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 57.7 mm
  • Internal Diameter On Outer Ring 79.4 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5152 lbf
  • Static Radial Load 1834 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 0.57 kg
  • Price（$） 58.12
Self Aligning Ball Bearings 2210-K-2RS-TVH-C3 dimension drawing
Download DWG Download PDF

Features

How Does 2210-K-2RS-TVH-C3 Bearing Ensure Smooth Operation?

2210-K-2RS-TVH-C3 Bearing features a double-row design with chrome steel rings and balls, providing excellent radial load capacity.
Its dynamic radial load rating of 5152 lbf ensures reliable performance in various applications.

The sealed construction and nylon cage help maintain smooth operation by keeping contaminants out.
With a maximum speed of 4,800 rpm, it offers a balance of durability and efficiency.

The C3 radial clearance allows for better thermal expansion handling, ideal for fluctuating temperatures.
Its tapered bore design ensures secure fitting, reducing slippage during operation.

Application

Industrial Uses of 2210-K-2RS-TVH-C3 Bearing
2210-K-2RS-TVH-C3 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life in dusty environments.

In automotive applications, 2210-K-2RS-TVH-C3 Bearing fits well in wheel hubs and transmissions, handling radial loads with ease. Its tapered bore provides a secure fit, reducing slippage during high-speed rotations.

For automation equipment, 2210-K-2RS-TVH-C3 Bearing’s double-row construction offers stability in robotic arms. The nylon cage reduces friction, making it suitable for smooth, precise movements.

In household appliances like washing machines, 2210-K-2RS-TVH-C3 Bearing’s lubricated design ensures quiet operation. The chrome steel balls enhance durability, even with frequent use.
